Help Center2.0mm-4.0mm Solar Tempered Glass
Related Products
FOB PRICE:USD3.95-4.5
· MIN ORDER QUANTITY :2600SQM
· Supply ability :100000SQM
· Per:Month
· Port:Fuzhou China
· Payment :T/T L/C
Item Name |
Solar tempered Glass |
Item No. |
PE019 |
Thickness range |
2.0mm |
Max size |
1000*2000mm |
Min size |
300*300mm |
Size |
1. side length L≤1000mm allowable deviation+0,-1.5mm |
2. side length L≥1000mm allowable deviation ±1mm | |
Solar Transmittance |
≥93.8% Wavelength Range 380-1100nm |
Diagona |
Difference ≤ 2mm |
Hardness |
3H |
Max iron content |
≤120ppm |
Warpage |
1.Global warpage≤0.3% |
2. Local warpage≤0.5mm measured on a distance of 300mm | |
Corner Cut |
Width 1-4mm |
Resistance to dirt |
Paste the 3M tape on the smooth side of AR glass in 20 cm²，Remove tape and insperction adhesion results.If the contamination less than 1 cm² and the quantity no more than 2pcs, it is passed. |
Roughness |
Smooth side average 0.4-1.2um |
Advantages |
1.Combined with nanometer anti-reflective coating technology, glass surface has a dense structure of high-gain film,which increase 2.3%-2.5% of solar transmittance. |
2.Good performance on acid and alkali resistance under terrible environments outdoor |
