Titanium Nitride PVD coating machine:
The machine can get all kinds of color coating on metal,glass,ceramic.
suitable for plating various hard metallic films and metallic compound films on the surface of metals and alloys having outstanding film quality, being widely applied to the surface treating area in such industries as high class decoration, watch, glasses, cutting tool and hardware,home products.
Technical parameter:
|
Mode Dimension |
LH-800 |
LH-1100 |
LH-1250 |
LH-1600 |
LH-1800 |
800*1000mm |
1100*1000mm |
1250*1500mm |
1600*1800mm |
1800*1800mm |
|
Maily application |
Metal decorative coating and Ceramic decorative coating |
||||
Coating mode and main confirguration |
Eight multi-arc targets |
Ten multi-arc targets |
Twelve multi-arc targets |
Twenty multi-arc targets |
Twenty two multi-arc targets |
Power source |
Electric-arc power, Filament power, |
||||
Process gas control |
Mass flowmeter + Electromagnetic ceramic valve |
||||
Vacuum chamber structure |
Vertical side opening door, pump system postposition, double water cooling |
||||
Vacuum system |
Molecule pump +Roots pump +Mechanical pump(8.0*10-5Pa) Diffusion pump +Roots pump +Mechanical pump(8.0*10-4Pa) |
||||
Workpiece baking temperature |
Normal temperature to 350 centi-degree PID control, radiation heating. |
||||
Workpiece motion mode |
Public rotation Frequency control: 0-20 rotation per minute |
||||
Measure mode |
Number display composite vacuum gauge: from atmosphere to 1.0*10-5Pa |
||||
Control mode |
Manual/Automatic/PC/PLC + HMI/PC four choice of control mode |
||||
Remark |
We can design the dimension of the equipment according to customer’s special technique requirement. |
||||
These are the coated metal products:
These are coated ceramic and glass products:
HCVAC can help you to enter the PVD coating easily by our vacuum coating machine and full range service. We will provide with most suitable technology according to your requirements.
We will make the special coating solution for each customer; combine the full set production technics to meet your requirements, to ensure high efficiency of production.
Easy to implement
To many people unfamiliar with the process, PVD coating technology seems complicated. However, with the right investments and a good support, it is easier than expected. HCVAC has developed a turnkey coating process that makes a PVD coating centre easy to implement. A complete coating process consists of several steps: stripping (depending on the part’s history); pre-treatment; quality control; cleaning & drying; fixturing & visual inspection; PVD coating; quality control & thickness measurement and post-treatment (depending on the application). These steps are all available from one partner: HCVAC Technology, including mature technics and coatings.
For more information, please feel free to contact us or visit our website: !
