Glass cutting machinery from China-YG-3826/2621 Series CNC Automatic Glass Cutting Machine:
1. Features
This automatic CNC-shaped glass cutting machine allows users to cut out any shape of glass with high precision. AUTO CAD designed graphs and figures, automatic cutting, with all the cutting data fully computer controlled. The operator can edit the glass size for cutting with computer. The computer can optimize the cutting size, and give out the data for processing, driven the machine to cut glass sheet automatically in high speed and high precision.
a. Use professional computer software equipped professional cutting and optimized composing system.
It features easy operation, high accuracy and fast speed. Cutting speed can be adjustable.
b. Cutting beam was imported from German high precision rack and rail. It features high accuracy.
c. Main parts were imported from brand products. It features high quality and long life.
d. Maintain and operation were easy for the machine. Edit the glass size for cutting with computer.
The computer can optimize the cutting size, and give out the data for processing, driven the machine
to cut glass sheet automatically in high speed and high precision.
Max Cutting Size (mm) 3660*2440mm
Max Cutting Speed (m/min) 0-120 (adjustable)
Cutting Accuracy (mm/m) ≤ ±0.15
Glass Cutting Thickness(mm) 1-19mm
Voltage (V) 220V/380V (Three Phases)
Dimension (LWH) (mm) 4700*3100*900mm
Weight: 2600Kg
Power: 9Kw
2. Normally Used Size we produce
Model |
Max.Glass Size |
Min.Glass Size |
Glass Thickness |
Weight |
Dimension |
YG-2621 |
1800*2600mm |
20*20mm |
3-19mm |
1500Kg |
3200*2300*1500mm |
YG-3826 |
2440*3660mm |
20*20mm |
3-19mm |
2500Kg |
4500*2900*1500mm |
Above is the normally used size, also we can make specially according to your requirement.
3. Remarks
Pkg: Seaworthy packing or customized
Terms: FOB/CIF/CFR/EXW
From Qingdao, China To_______,
Delivery Time: During 30 Days After We Receive Your First Payment
Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and
The rest 70% is effected while delivering the goods.
5. Trademark: SUNNY
Guarantee & Aftersales service:
1)Guarantee the complete machine for 18 months, except the consumable parts.
2) 24hour technical support by email or calling.
3) User-friendly English manual for machine using and maintaining.
Contact person: Ms.Sailing He
Mobile: +86 18005318120
Skype: judy.he74
TM: cn209682722
