multifunctional CNC Automatic glass cutting machine
(any shape glass cutting table)
Introduction:
1. Automatic loading cutting and breaking function
2. High cutting accuracy with automatic correction
3. Less space occupation and easy operation
Product Function:
used in glass cutting, automatic loading glass , breaking glass and ratation 360° autoamtic,
no need labour to move it.
Product Size: 19 square meter(20GP)
Operation Requirement: 2 operators are needed. One for cutting and the other one for dividing.
Cutter-Base: Adjusting pressure according to the thickness of glass,cutter head with 360 degree rotatable, knife cut under cushion(cutting accurately for any straight line and special-shaped glass)
PRODUCT FEATURES:
u First Class Parts: All key components are of world class quality, with motors from YASKAWA, racks from Taiwan and so on. All providers are strictly selected to ensure best quality.
u The automatic loading & cutting integrated machine; integrating the function of loading. Linear cutting, irregular shape cutting, air floating, breaking, auto-walking together, it also has remote control function, fully automatically controlling from loading to cutting, which will greatly increase the working efficiency and reduce the cost.
u Highly Automated & Intelligent: using intelligent CNC system to achieve goal of saving humanity and cost down.
u Gas Floatation: improving productivity and in cooperation with take-in and take-out machine, you got a pipe-line machine for cutting, improving productivity maximally.
u Stable and Precise: automatic lubing and pressure adjusting ensures best effects.
u Simple and User-friendly: simple and elegant designing produces simplified operation and management, with the bonus of low maintenance cost.
ELECTRICAL & PHISICAL PARAMETERS
Size (mm) |
Power Supply |
Capacity |
Pressure |
Total Weight |
2900×3000×1200 |
≤ 12 kw |
1.2MPa |
1500 kg |
CUTTING PARAMETER
CUTIING SPEED (m/min) |
LINEAR PARELELLISM(mm/M) |
DIA-ANGLE PRECISION(mm/M) |
|||
0~120(dimmable) |
3~19 |
2500×1900 |
≤±0.01 |
≤±0.20 |
Remarks:
A. Pkg: for long time transportation
B. Terms: Freight On Board (FOB Qingdao)
C. From Qingdao, China
D. Delivery Time: During 30 Days After We Receive Your First Payment.
E. Payment: Telex Transfer (T/T), 30% be Paid as deposit, and the rest 70% is paid before delivery the
machine.
F. Guarantee period: 1 year from the date of customer receiving the machines.
1)Guarantee the complete machine for 18 months, except the consumable parts.
2) 24hour technical support by email or calling.
3) User-friendly english manual for machine using and maintaining.
