Double Glazed Glass Washer
Main Features
LB series of vertical glass washing machine can be matched with Insulating Line. It combined function of three steps washing, used with stepless regulator driving system, which is easily to wash different size glass. Washing area has installed with stainless steel or other special treatment steel. Optional for hard and soft brusher device, which is special design for hard Low-e Glass washing machine can be designing according to customers requirement.
Technique Parameter
| Model | Max.glass size | Min.glass size | Glass Thickness | Power Voltage | Weight | Size of line |
| LB2500 | 2500*3000mm | 300*500mm | 3-12mm | 19Kw | 4500Kg | 8200*1850*3100mm |
| LB2200 | 2200*3000mm | 300*500mm | 3-12mm | 19Kw | 4200Kg | 8200*1850*3000mm |
| LB2000 | 2000*2500mm | 300*400mm | 3-12mm | 15Kw | 3500Kg | 7000*1650*2800mm |
| LB1800 | 1800*2440mm | 300*400mm | 3-12mm | 15Kw | 3000Kg | 6880*1650*2700mm |
| LB1600 | 1600*2000mm | 300*400mm | 3-12mm | 12Kw | 2650Kg | 6200*1650*2500mm |
More Details
Other Related Machines
Semi-automatic Glass Cutting Machine
Manual glass Cutting Machine
Glass Loading Machine
Glass Cutting Line
Guarantee & Aftersales service
1.Guarantee the complete machine for one year, except the consumable parts.
2.24hour technical support by email or calling.
3.User-friendly english manual for machine using and maintaining.
Remarks
1. Pkg: Each PC In Wooden Cases
2.Terms: Freight On Board (FOB, Qingdao Port)
3.From Qingdao, China To_______,
4.Delivery Time: During 30 Days After We Receive Your First Payment
5.Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and the rest 70% is effected while delivering the goods
6. Our Trademark: SUNNY
