YG-500 Mini Horizontal Glass Washing & Drying Machine:
Structure :
• GB square tube frame; 1.0mm iron spray cap.
• Washing, drying and tank parts are stainless steel
• Transmission/washing/ absorbent cotton roller uses anti-high temperature and anti-acid materials with long life.
• Speed is controlled by motors, and can be easily moderated.
• Temperature controller changes the blowing speed.
• This equipment is roller driven, large process range, circulating water cleaning glass at once.
Basic parameters:
Glass size range: 50*50 - 480mm; glass thickness 1-12mm;
Four pairs of brushes, three pairs of absorbent cotton rollers Anhui
9 kilowatts of electric power
CVT: 0.55kw, 380v ( stepless ) or customized
Pump: 150w, 380v submersible pumps Shanghai or customized
Gear Motor: 1.1kw, 380v Guangdong
Weight: 400KGS
Dimensions: 1900 × 1000 × 1000 (mm)
Basic Configuration
Water tanks, washing and drying section 204 stainless steel enclosure
Roller, brush, sponge roller. Anhui, native NBR
CVT: 0.55kw, 380v (stepless) Guangdong
Pump: 150w, 380v submersible pumps Shanghai
Gear Motor: 1.1kw, 380v Guangdong
GB square tube frame
12mm steel finishing plates
Wash cold drawing board plating section pole
Finishing the cleaning section aluminum plate
Hollow glass washer-BX1600 Horizontal Glass Washing and Drying Machine:
1. Features:
It is used to wash 3-12mm and 35mm-thinner glass, with the horizontal structure, it is stable
to transmit; stable performance with DELIXI contactor, push-button switches and pilot light.
It adopts frequency stepless speed and is easy to operate as the button is concentrated on the
operation table, the height of washing tank can be changed to meet the requirement of any
glass thickness. Three groups of brushes assure the washing quality while two pairs of air
knives assure the drying. Inspecting light is equipped to examine the glass quality.
2. Technical Data
Power voltage: |
380VAC |
Frequency rate: |
50Hz |
Transmission speed: |
1-5m/min |
Thickness of washing glass: |
3-35mm |
Power rate: |
9.7Kw |
3. Other Models
Model |
Max. Glass Size |
Min. Glass Size |
Glass Thickness |
Power |
Weight |
BX1600 |
1600*3000mm |
300*400mm |
3-25mm |
9.7Kw |
2200KKg |
BX1800 |
1800*2440mm |
300*400mm |
3-25mm |
20Kw |
3000KKg |
BX2000 |
2000*2440mm |
300*400mm |
3-25mm |
22Kw |
3300KKg |
BX2500 |
2500*3000mm |
300*400mm |
3-25mm |
29Kw |
3800KKg |
4. Remarks
Pkg: Seaworthy packing or customized
Terms: FOB/CIF/CFR/EXW
From Qingdao, China To_______,
Delivery Time: During 20 Days After We Receive Your First Payment
Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and
The rest 70% is effected while delivering the goods.
5.Trademark: SUNNY
Guarantee & Aftersales service:
1)Guarantee the complete machine for 18 months, except the consumable parts.
2) 24hour technical support by email or calling.
3) User-friendly English manual for machine using and maintaining.
Contact person: Ms.Sailing He
Mobile: +86 18005318120
Skype: judy.he74
TM: cn209682722
