SJ06-3700 Aluminum Double-head Cutting Machine for Aluminum Windows and doors
1.Description:
It is used for processing the pvc and aluminum profile , it has the feature of easy operation, reliable performance, advanced technology, easy to maintain. The cutter which is made of hard alloy saw blade has fast cutting speed, high efficient and accuracy. The two saw head can work together or seperatly, it can complete the cutting lenth as request for one time, the saw head can be turned to 45 and 90 degree.
2.Main Technical Parameters:
Power Supply:380V,50Hz
Input Power:3.6Kw
Air pressure:0.5-0.8Mpa
Blade Rotational Speed:3087r/min
Saw Blade Specification:D=450mm d=30mm
Cutting Length:Min580mm Max3700mm
Cutting Angles:45°90°
3.Relevant machine:
1)Double miter cutting saw machine for aluminum windows and doors
2)Corner connector cutting saw machine for aluminum windows and doors
3)Double-head Copy Router(copy milling machine) for aluminum windows and doors
4)End-milling Machine for Aluminum Windows and doors
5) Corner crimping machine for aluminum windows and doors
6)Press(punching)machine for aluminum windows and doors
4.Note:
Most Electrics Part are CE or UL Standard
Payment: Telex Transfer (T/T), 30% be paid after confirming the order and the rest 70% is effected while delivering the goods.
Package: Each PC in wooden cases.
Port of Loading: Qingdao, China
Delivery Time: During 10-15 working days after we receive your first payment.
Trade Mark:SUNNY
