PVC Window Machine Single-head Reinforcement Screwer

PVC Window Machine Single-head Reinforcement Screwer thumbnail-1
PVC Window Machine Single-head Reinforcement Screwer photo-1
US$ 4,000 - 80,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Brand Name:
SUNNY
Place of Origin:
Shandong, China
Certification:
Other
Contact Supplier Request Quote Chat Now
Nanjing Vacuum Bagging Film Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Brand Name SUNNY
Place of Origin Shandong, China
Certification Other
After-sales Service Provided Engineers available to service machinery overseas
Warranty 18 months
Voltage 380V or customized
Product Type PVC Profile
Condition New

PVC Window Machine-----Single-head Reinforcement screwer :



Technical Prameter:



Power supply :                          380V 50HZ or according to need

Input power:                             1KW

Air pressure:                             0.6-0.8 Mpa

Processing profile length:        300-3000mm

Processing profile height:        100mm

Depth of profile steps:              32mm

Screw specification(GB):         Diameter 4.2*13    4.2*16   4.2*19mm, Cross

                                                 Recessed countersunk head screw.(if diameter is too big,need to order )

Screwdriver specification:      Diameter 6.35x110mm

Tight wire turnovers:              2-5% ( related to the quality of screw)

Positioning distance(2 points): 100mm

Screw distance:                     250-380mm

Thickness of steel liner:         1.0-2.0mm





PVC Window Machine Single-head Reinforcement screwer



4. Remarks

1. Pkg: Seaworthy packing or customized

2.Terms: FOB/CIF/CFR/EXW

3.From Qingdao, China To_______,

4.Delivery Time: During 30 Days After We Receive Your First Payment

5. Payment: Telex Transfer (T/T), 30% Be Paid After Confirming The Order and

                     The rest 70% is effected while delivering the goods

6.Trademark: SUNNY





Guarantee & Aftersales service:

1)Guarantee the complete machine for 18 months, except the consumable parts.

2) 24hour technical support by email or calling.

3) User-friendly English manual for machine using and maintaining.



Contact person: Ms.Sailing He

Mobile: +86 18005318120

Skype: judy.he74

TM: cn209682722
