Capacity of HPC machines is defined according to the rate at which they will consume / process a stockpile of raw feed material (“Run of Mine” or “Bank-run” material). This is material typical of Placer deposits which contain large and small rocks, gravel, stones and sandy material. Processing capacity is limited primarily by the fraction of undersize material screened from this raw feed and fed onto the HPC’s Concentrator Belt. Accordingly, should you feed the HPC machine with material which is already undersize (or the deposit you are processing consists mostly of fine/sandy material), all of this material will pass directly to the concentrator belt and the effective operating capacity of the machine will be based on this.
Please refer to the attached Production Capacity Tables and Material Flow Diagrams for capacity information corresponding to the material to be processed.
Integrated Feed Conveyor & Feed Material
• Hopper capacity is 0.2m3 (7 cubic feet) and is fitted with a detachable, horizontal Grizzly to remove +75mm (+3'') material.
• Feed Rate is fully controllable by a combination of Variable Speed Drive to adjust conveyor speed and bolt-on choke plate to allow for complete flexibility of material sizing.
• Hopper can be fed manually or using a mini-excavator.
Drive system
• Concentrator Belt and Trommel drive system: 1.5kW (2.0 HP) 3-phase Drive Motor with Reduction Gearbox.
• Integrated Feed Conveyor drive system: 0.4kW (0.5 HP) 3-phase Drive Motor with Reduction Gearbox.
• Each motor is controlled by a Digital Variable Frequency Controller housed within a waterproof enclosure. Note: Single-phase power supplied to the HPC-15 is supplied directly to the Variable Frequency Controllers which convert the power to 3-phase power required by the Drive Motors. The first Variable Frequency Controllers can be adjusted to set the speed of the Concentrator Belt and Scrubbing / Screening Trommel and the second Controller and be adjusted to set the Feed Rate of the Feed Conveyor.
Electrical Supply Requirements
Electrical Supply must be Single Phase 220V - 240V and 60Hz / 50Hz.
The motors on the HPC-15 have a combined rating of 1.9kW. When considering startup 1 “inrush” current, we recommend a minimum of 5VA or 6kW Generator (excludes power required for electrical water pump). HPC-15 is supplied with Electrical Supply cable. Note: Electrical Generator is not supplied with the HPC-15.
Water supply requirements
The HPC-15 requires water supply of approximately 40 gallons/minute (160 liters/minute) at a pressure of approximately 45psi (310 kPa). Any electrical, petrol or diesel powered pump capable of providing this water flow may be used. The Water Supply must be connected via a 2” hose (“lay-flat” or discharge hose) clamped onto the inlet nipple on the Water Manifold. Note: Water Pump and connection hose are not supplied with the HPC-15.
Feed material
Maximum: 6” (150 mm) minus material. Recommended: 3” (75mm) minus.
Trommel
Scrubbing & Screening Trommel is 2.8m long with 0.4m diameter and 1.65 m 2-stage Scrubber. Screen is 8mm.
Dimensions
Length 5.63m, Width 1.76m, Height 1.80m, Weight: 1,700 kg
Shipping info
Optimal shipping configuration: 1 X HPC-15 in 20’ container. International customs code: HS #: 8474.10.00 (1) Sorting, screening, separating or washing machines
Trailer
Single-axle trailer with Pintle-hitch (40mm /1.6’’ ID) - Ball Hitch available - to be specified on order.
Manning
1 equipment operator required.
Note: for safety reasons, it is always best to have at least 2 people present when operating machinery.
Pre-sale services:
a. Professional engineer design the production line for you
b.Recommend suitable equipment according to your special demand.
During-sale services:
a.Pre-check and accept products before delivery
b.Send technicians to the jobsite for guiding the installation and adjustment
c.Training operators and finishing the check to satisfy your requiremnet
After-sale services:
a.Common problem can be solved through web in 24 hours,complex problem can be reacted immediately in 24 hours and solved as soon as possible
b.To establish long-term friendship, we will regulary contact with our customers.
Packing
FLC&LCL Export standard container 20/40 GP.
Steel support & iron sheet sea-worthy package.
Load: export software scientific loading work
Transportation
By sea freight.
MSK/MSC/APL/EMC/WANHAI/KLINE
Air delivery services
We will remind you before boat arrives.
