The bucket chain gold dredger is one of the mechanical dredgers.
A bucket chain gold dredger is a stationary dredger that is equipped with a continuous chain of buckets, which are carried through a structure,the ladder. This ladder is mounted in a U-shaped pontoon.
The drive of the bucket chain is on the upper side. The bucket chain gold dredger is anchored on six anchors.
During dredging, the buck chain gold dredger swings round the bow anchor by taking in or paying out the winches on board. The buckets, which are filled on the underside, are emptied on the upper side by tipping their contents into a chute along which the dredged material can slide into the barges moored alongside.
The chain is driven by the so called upper tumbler at top of ladder frame, which is connected either via a belt to the diesel or directly to an electro motor or hydro-motor.
Serial Number |
Parameter |
Notes |
Length Overall |
38.5m |
Bucket ladder in horizontal |
Hull Length |
32.4m |
|
Hull Width |
6m |
|
Hull Depth |
1.18m |
|
Mean Draft |
0.7m |
|
Dredging Depth |
15m |
|
Sand Output |
250m³/hr |
|
Weight |
120 tons |
|
Engine Power |
250kw |
|
Delivery Times |
30 days |
| Our Service |
1.Customized design and pre-sale service. |
| 2.Lifetime after-sale service. |
| 3.On-site installation and worker training. |
| 4.Provide wear parts in time. |
