Automatic Film Pallet packing and wrapping Machine/Automatic turntable pallet stretch packer/wrapper
Product Description
1.Pallet wrapping machine use LLDPE stretch film as the main packing material to wrap the bulk cargos stacked on the pallet
2.Film provides extra support during transportation and storage to protect them from dust, moisture or damage
3.The pallet wrapping machine has been widely used in industries such as glassware, tools, electric & electronic, paper,pottery, food & beverage, etc
Technical Specs New Pallet Stretch Wrapping Packing Machine
Pallets/Hour |
15-25 pallets/hour |
Pallet Size(special design available) |
1400mm*1400mm(L*w) |
Pallet Height(special design available) |
2100mm(H) |
Max. Pallet Height(special design available) |
2000kgs |
Starting Mode |
Soft start |
Diameter(special design available) |
1500mm |
Height |
110mm |
Speed |
1-12rpm(adjustable) |
Max.stretch |
300% |
Installed Power |
1.2 kw |
Power Supply(special demand available) |
380V,three-phase,50Hz |
Advantage of this luggage wrapping machine:
Luggage Wrapping Machine Specially designed for packaging luggages, cargos and goods in airports, docks s & stations.Suitable for fast transporting and storing.
Adopting Programmable logic control reliable in performance, convenient in operation.
It can protect the package against dust and damp or damage.
Photocell detector automatically senses luggage height.
With pre-stretch carriage, pre-stretch rate up to 300%, film savings.
Holder speed adjustable.
Film tension adjustable. Easy tracking for wrap counter device
Main Features
1. High efficiency and low electricity-consumption, convenient in operation.
2. The wrapping type and times can be designed on customers’ requirements.
3. photoelectric sensor test pallet height automatic
4. Auto reset of turn table
5. Pre-stretch ratio: 300%
6. Programmable control and frequency converter is available.
7.PLC control ,manual optional. Wrap cycle (top, bottom, reinforcement) adjustment.
Variable lift speed/ film tension control. Film up/down controls.
8.pallet wrapping machine soft start and soft stop.
9.Suitable for heavy pallet
10.remote control system ,fully automatic
