6KVA Portable Soundproof Diesel Electric Generator with Stable Quality
| MODEL | AD3800DSE | AD5800DSE | ||||
| Rated frequency(HZ) | 50 | 60 | 50 | 60 | ||
| Rated voltage(V) | 220/230 | 240/120 | 220/230 | 240/120 | ||
| Rated current (A) | 12.2 | 13.8/27.5 | 18.3 | 20.8/41.7 | ||
| Rated output power(kVA) | 2.0 | 2.5 | 5.5 | 6.0 | ||
| DC output | 12V/8.3A | |||||
| Power factor | 1.0 | |||||
| Phase | Single-phase | |||||
| Dimension(LXWXH)(mm) | 830× 520× 40 | 910× 530× 740 | ||||
| Packing size(LXWXH)(mm) | 900× 565× 770 | 990× 570× 770 | ||||
| Net/Gross weight(kg) | 135/143 | 175/183 | ||||
| Structure model | Silent cart type | |||||
| Engine model | HY178FE | HY186FE | ||||
| Engine type | Single-cylinder, 4-stroke, air-cooled, direct-injection, diesel engine | |||||
| Displacement(cc) | 296 | 406 | ||||
| Compression rate | 20: 1 | 19: 1 | ||||
| Rated output/Speed KW (HP)/rpm) | 3.7(5.0)/3000 | 5.7(7.8)/3000 | ||||
| Starting system | Recoil/Electric start with battery | |||||
| Fuel tank capacity(L) | 16 | |||||
| Lube capacity(L) | 1.1 | 1.65 | ||||
| Fuel type | Diesel0#(summer), diesel-10#(winter) | |||||
| Lube brand | SAE10W30(above CC grade) | |||||
| Low oil pressure alarm system | With | |||||
1.Q:Are you a factory or trading company?
A:We are a factory.
2.Q:What is the Quality Warranty for the products?
A:We offer 1 year quality warranty for all of our products.
3.Q:Where is your factory located? How can I visit there?
A: Our factory is located in Taizhou City, Zhejiang Province, China, about 2 hours train from Shanghai . All our clients, from home or abroad, are warmly welcome to visit us!
4.Q:What is the material of your products?
A: Only New material can be used for our products.
Materials for Generator: 100% Pure Crankcase, 100% Pure Copper Wire
Materials for Water Pump: 100% Pure Auminium Pump body and Crankcase
5.Q:What is Minimum Order quantity?
A: MOQ 50/100 pieces for different products.
You are welcomed to consult for details.
6.Q:How does your factory do regarding quality control?
A: From the internal parts to the outside packing, we not only make standard quality test,but also think ahead for a better solution. Except company QC system, We have achieved CE & SONCAP certificate.
