Impulse transfer vertical Flow Water Meter
| MAIN TECHNICAL SPECIFICATIONS | ||||||||
| Type |
Size (mm) |
Class | qs | qp | qt | qmin | Minimum | Maximum |
|
Overload Flow |
Permanent Flow |
Transitional Flow |
Minimum Flow |
Reading | Reading | |||
| m3/h | L/h | m3 | ||||||
| LXSG-15 | 15 | B | 3 | 1.5 | 120 | 30 | 0.00005 | 99,999 |
| LXSG-20 | 20 | B | 5 | 2.5 | 200 | 50 | 0.00005 | 99,999 |
| LXSG-25 | 25 | B | 7 | 3.5 | 280 | 70 | 0.00005 | 99,999 |
| LXSG-32 | 32 | B | 12 | 6 | 480 | 120 | 0.00005 | 99,999 |
| LXSG-40 | 40 | B | 20 | 10 | 800 | 200 | 0.00005 | 99,999 |
| LXSG-50 | 50 | B | 30 | 15 | 3000 | 450 | 0.00005 | 99,999 |
| DIMENSIONS | |||||
| Type | Size |
L Length |
B Width |
H Height |
d |
| mm | Connecting Thread | ||||
| LXSG-15 | 15 | 165 | 98 | 116 | G3/4B |
| LXSG-20 | 20 | 190 | 98 | 117 | G1B |
| LXSG-25 | 25 | 260 | 103.5 | 124 | G11/4B |
| LXSG-32 | 32 | 260 | 103.5 | 124 | G11/2B |
| LXSG-40 | 40 | 300 | 125 | 162 | G2B |
| LXSG-50 | 50 | 300 | 125 | 162 | G21/2B |
| 280 | 160 | 187.5 | Flange connect ISO 7005-2:1988 | ||
| φD=125 | |||||
Features:
Multi-jet, Dry-dial, easy to maintenance;
Magnetic drive reliable characteristic, long working life;
Register is sealed in the capsule with special liquid keep a clear presentation in along term servise;
Selected high quality materials for steady & reliable characteristic
Technical data conform to international standard ISO4064 Class B
Working condition:
Water temperature: 0.1°C~40ºC for cold water meter.
Water Pressure: ≤ 1.0Mpa or 1.6Mpa
Maximum permissible error:
in the lower zone from qmin inclusive up to but excluding q t is ± 5%;
in the upper zone form q t inclusive up to and including q s is ± 2%.
Hot water meter ±3%
Packaging and Transport :
LXSG type - Multi jet
LXDG type - Single jet
LXHY type - Rotary piston
Each meter is packed in a small box. Outer packing is carton .
LXLC type - Industrial flange
LXXG type - Agistrar Irrigation & Sewage water
Each meters is packed in a carton / wooden box .
