Help CenterGWD400 Industry Electronics S Style Vehicle Dynamometer 50ton
Related Products
-
GWD500 RS232 Output High Strength Linked-type Digital DynamometerUS$ 550 - 650MOQ: 1000 Pieces -
GWD600 Digital Crane Hanging Scales Weight Sensor 30 TonUS$ 1200 - 1300MOQ: 1000 Pieces
-
GWD700A Heavy Duty D Ring Wireless Shackle Bolts Load CellUS$ 680 - 8560MOQ: 1000 Pieces
-
GWD700 Wireless Tension Shackle Load Cell 50TonUS$ 800 - 7160MOQ: 1000 Pieces
-
GWD200 GALOCE Wireless Dynamomter With Handheld Indicator 10tonUS$ 480 - 4500MOQ: 1000 Pieces
♦ Aluminum and alloy steel capacities are powder coated.
♦ The acceleration of gravity can be regulated through red infrared remote controller according to different places value.
Specifications of industry electronic S style vehicle dynamometer 50ton
GWD400 Size of industry electronic S style vehicle dynamometer 50ton
| MODEL | Cap(t) | Div(kg) | A | B | C | D | φ | H | Material |
| GWD400-1t | 1 | 0.5 | 245 | 112 | 37 | 190 | 43 | 335 | Aluminum |
| GWD400-2t | 2 | 1 | 260 | 123 | 37 | 195 | 51 | 365 | Aluminum |
| GWD400-3t | 3 | 1 | 260 | 123 | 37 | 195 | 51 | 365 | Aluminum |
| GWD400-5t | 5 | 2 | 285 | 123 | 57 | 210 | 58 | 405 | Aluminum |
| GWD400-10t | 10 | 5 | 320 | 120 | 57 | 230 | 92 | 535 | Alloy Steel |
| GWD400-20t | 20 | 10 | 375 | 128 | 74 | 260 | 127 | 660 | Alloy Steel |
| GWD400-30t | 30 | 10 | 420 | 138 | 82 | 280 | 146 | 740 | Alloy Steel |
| GWD400-50t | 50 | 20 | 465 | 150 | 104 | 305 | 184 | 930 | Alloy Steel |
| GWD400-100t | 100 | 50 | 570 | 190 | 132 | 366 | 229 | 1230 | Alloy Steel |
| GWD400-200t | 200 | 100 | 720 | 265 | 183 | 440 | 280 | 1362 | Alloy Steel |
GWD400 Weight of industry electronic S style vehicle dynamometer 50ton
| Model | GWD400-1t | GWD400-2t | GWD400-3t | GWD400-5t | GWD400-10t |
| Unit Weight(kg) | 1.6 | 2.1 | 2.1 | 2.7 | 10.4 |
| Weight with shackles(kg) | 3.1 | 4.6 | 4.6 | 6.3 | 24.8 |
| Model | GWD400-20t | GWD400-30t | GWD400-50t | GWD400-100t | GWD400-200t |
| Unit Weight(kg) | 17.8 | 25 | 39 | 81 | 210 |
| Weight with shackles(kg) | 48.6 | 73 | 128 | 321 | 776 |
GWD400 application of industry electronic S style vehicle dynamometer 50ton
⇒ What detailed information do I need to provide if I want to place an order?
√ We need to know the following information: Capacity, Usage and other related parameters you need.
⇒ Do you have any discount?
√ Yes, if you buy large QTY, please send us a email, we will give you a big discount.
⇒ What terms of payment are available?
√ We accept T/T, L/C, Trade assurance, Secure payment, Western Union, Paypal, Money Gram, etc.
⇒ When will you arrange the production?
√ We will arrange the production immediately after receiving your payment.
⇒ How do you ensure good product quality?
√ We have a complete quality control system, all of our products are fully checked by IQC, OQC departments before shipping to our clients.
