Aluminum Notching Saw Machine V Notching Cutting Saw for Aluminum Window And Door
LJK-500
Specification:
1. High performance notching saw designed for the field of aluminum curtain-wall and lighting skylight processing with the special angle at profiles end surface.
2. Equipped with magnetic ruler control system, can display digits of cutting angle and worktable height.
3. Convenient worktable and locating device adjustment,can achieve special end surface angle processing.
4. The two saw blades can swing freely at+45º~-45º, cutting special angles.
5. Circuitry has phase sequence relay and automatic power off device when opening electric cabinet, greatly improve safety.
6. Two moving saw units working at the same time while the profile is stationary, high accuracy.
7. This machine can realize clamping several profiles horizontally and vertically at the same time because of wider working plate.
Technical Parameter:
Power supply |
Made to order |
Hydraulic gearbox motor power |
2*2.2 KW |
Rotary speed |
2800r/min |
Operation air pressure |
0.5~0.8Mpa |
Angle between 2 saw blade |
-45°~+45° |
Max. cutting depth(vertical and horizontal) |
150mm |
Saw blade specification |
φ500mm*4.4mm*φ30mm Z=120 |
Dimension |
3200*1400*1800mm |
Weight |
1500kg |
1. Customized service:
Free industrial information, free investment analysis for windows, doors, and curtain wall project, free layout design for window, and door and curtain wall product line.
2.After sales service:
One year guarantee
Free adjustment
Free training to operation and maintenance workers
Provide quick supply of spare parts for window and curtain wall companies.
We support Trade Assurance on Alibaba, which is a free payment protection service for buyer regarding product quality and transaction security.
JINAN DEGA MACHINE CO.,LTD.(DECALUMA) was founded in 2006, offering products that include a wide range of machine for manufacturing aluminum window door & curtain wall, single and double-head sawing machines, machines and equipment for working and assembling aluminium and PVC window frames. We started as a small operation, but now we are the leading premium supplier in the segment of profile & curtain wall machining for a vast array of different requirements and materials. DECALUMA is a customer-oriented company,we are always just around the corner from you to help you choose a good machine, such as: cnc machining centre, aluminum cutting machine, aluminum hole punching machine, corner key cutting saw, aluminum profile drilling machine, corner crimping machine, end milling machine, aluminum profile bending machine, copy router and thermal break machine and so on.
2. When you can do if my machine have some problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can send our engineers to repair your machines
3. When can we arrange shipment?
We usually arrange shipment within 15 days after getting deposit,but customized machines should be more than 25 says
4. Are you trading company or manufacturer?
Manufacturer(OEM)
5. Quick details about our company
Company Name |
JINAN DEGA MACHINE CO.,LTD. |
Year established |
2006 |
Address |
No.389,TIANCHEN ROAD,JINAN CITY,250101 CHINA |
Business type |
Manufacturer |
|
Product range |
CNC Machining Centre, aluminum cutting machine, corner key cutting, end milling machine,punching machine,copy router, crimping machine, drilling and bending machine |
Product advantage |
Using advanced solidworks design platform |
Management certificate |
ISO9001,national patent |
Fair we attend |
Shanghai and Beijing international windows show |
E-catalog |
available |
MOQ |
1 set |
Payment terms |
TT or L/C |
Shipping port |
Qingdao port |
