Glazed galvanized aluminum corrugated IBR sheet forming machine
1)Our roofing sheet roll forming machine has hand knife at the end of the line.It can help you save Raw Material.
2)Our roofing sheet roll forming machine has two cylinders at least. Because the frictional force of shearing machines is very big. One cylinder machine has shorter using life.
3)Our roll forming machine has protective screening. Safer for the workers.
Just for your reference
Working flow
Technical parameter
Suitable Material |
Material |
GI, PPGI, PPGL |
Width |
1000 mm |
|
Thickness |
0.3-0.8mm |
|
Material of rollers |
High grade 45# forged steel, surface hard chromium plating |
|
Rows of rollers |
Up layer : 13 stations Middle layer : 12 stations Down layer : 12 stations |
|
Material of shafts |
High grade 45# forged steel |
|
Diameter of shafts |
70mm |
|
Material of blade |
Cr12 Heat Treatment |
|
Cutting Mode |
Hydraulic Guide Column |
|
Speed |
20-25m/min |
|
Side plate thickness |
16 mm |
|
Chain size |
1 inch |
|
Total power |
7.5 kw |
|
Voltage |
380V 50HZ 3Phase |
|
Appearance size (About) |
7000mm*1500mm*1600mm |
|
Weight(About) |
8 tons |
|
Electronic control system |
PLC (Delta) Touch Screen |
|
Terms of payment
1) Payment: 30% T/T prepaid, and pay the balance before shipping.
2) Delivery time: 30 working days.
3) Guarantee period: 12 months limited warranty starting from date of delivery. Shipping cost for parts to be replaced during warranty period have to be borne by the customer.
4) Spare parts: bearings, buttons, chains, magnetic valve, protective tube etc.
5) Installation and training:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and CD to teach you to install and operate.
c. COST OF INSTALLATION:
The buyer should pay the installation charges (USD 80 one man one day). To the seller’s appointed account by T/T before the seller’s technicians go to the buyer’s factory. The buyer pays the seller’s technicians travel cost outside China, including round air tickets fee, accommodation and food, provide transportation from living hotel to the work place, necessary communication, and insurance, etc.
FQA
1. what is your guarantee period?
Guaranteed against malfunctions due to manufacturing defects for 12 months from the date of loading.
machine in my factory?
2.How to visit our company:
A.Fly to Beijing airport: By high speed train From Beijing Nan to Cangzhou West station (1 hour),then we can pick up you.
B.Fly to Tianjin Airport: By high speed train From Tianjin West station to Cangzhou West station ,then we can pick up you.
