YC7314ab is an odourless two component polyurethane system.The product can be filled for reduced shrinkage.
PROPERTIES
--Very rapid demould times
--Ultra low viscosity
--Good thermal resistance
--Simulates Polypropylene
PHYSICAL PROPERTIES
YC7314A |
YC7314B |
MIXTURE |
|
Material |
Polyol |
Isocyanate |
|
Appearance |
White liquid |
Brown liquid |
Beige liquid |
Density @ 25°C |
0.99 g/ml |
1.12g/ml |
1.06 g/ml |
Viscosity @ 25°C |
60mPa.s |
65mPa.s |
|
Pot life (200 g) @ |
1'30"-2' |
||
20°C |
|||
Demould time |
20-25 minutes |
||
20 g,3mm @ 25°C |
MANUAL PROCESSING CONDITIONS
-- Ensure that the mould is clean and dry. For flexible moulds, usesilicone rubber.
-- Shake the Part A container thoroughly in order to homogenise the resin.For best results, make sure the two components are at least 20°C before mixing.
-- Weight both parts 1:1
-- When using unfilled, add the correct amount of Part B to the Part A and stir for 15 seconds. Pour carefully in one place into the mould in order to avoid air inclusion.
-- Vacuum casting into silicone moulds. （vacuum 30seconds）
-- Put the silicone moulds into pressure tank（maintain pressure 10minutes）
-- The casting can generally be demoulded in20-25minutes at room temperature.
HANDLING PRECAUTIONS
Normal health and safety precautions should be observed when handling these products:
l ensure good ventilation,
l wear gloves and safety glasses.
For further information, please consult the product safety data sheet.
STORAGE CONDITIONS
Shelf life of both parts is 9 months in a dry place and in original unopened containers at a temperature between 15 and 25° C. Any open must be tightly closed under dry nitrogen blanket.
