Hexagonal Wire Mesh
gabion mesh/ galvanized hexagonal mesh/
pvc coated hexagonal mesh/stainless steel hexagonal mesh
Material:
Low carbon steel wire, galvanized wire, PVC coated wire, stainless steel wire
Weaving:
Straight twist, galvanizing before weaving, hot-dipped galvanized, electro galvanized and PVC-coated, etc.
Hexagonal wire mesh features excellent corrosion resistance in all of its forms and serves well as a fencing solution for light duty applications such as poultry farming.
Characteristic:
(1) Easy to use
(2) Simple construction
(3) Strong resistance to natural damage, corrosion and adverse weather
(4) It can withstand large-scale deformation without collapse. Fixed heat preservation and insulation
(5) Better corrosion resistance
(6) Saving transportation cost and occupying little space
(7) The thickness of galvanized protective layer can be made according to the requirements of customers
(8) PVC protective layer will greatly increase the service life of the network, and the choice of different colors, so that it can integrate with the surrounding natural environment.
Purpose:
(1) Fixed, heat preservation and heat insulation of building wall;
(2) Power plant pipes, boiler insulation;
(3) Antifreeze, residential protection, landscape protection;
(4) Raising chickens and ducks, isolating the houses for chickens and ducks, and protecting the poultry;
(5) Protect and support seawall, hillside, road and bridge and other water and wood works.
|
Product Name |
Mesh (SWG) |
Silk number (SWG) |
Wire diameter (mm) |
Width X Lenght |
Weight (kg / roll) |
Roll diameter (mm) |
Remarks |
|
Straight twist Hexagonal Wire Mesh |
1/2 | 22 | 0.71 | 3'x100' | 15.00 | 150 | The width can be produced within 2 meters, and there are two kinds of single and double sides. |
| 1/2 | 23 | 0.62 | 3'x100' | 11.50 | 150 | ||
| 1/2 | 24 | 0.56 | 3'x100' | 09.30 | 140 | ||
| 1/2 | 25 | 0.51 | 3'x100' | 07.50 | 130 | ||
| 5/8 | 22 | 0.71 | 3'x100' | 13.00 | 150 | ||
| 5/8 | 23 | 0.62 | 3'x100' | 10.00 | 140 | ||
| 5/8 | 24 | 0.56 | 3'x100' | 08.10 | 130 | ||
| 5/8 | 25 | 0.51 | 3'x100' | 06.70 | 120 | ||
| 3/4 | 21 | 0.81 | 3'x100' | 14.80 | 170 | ||
| 3/4 | 22 | 0.71 | 3'x100' | 11.00 | 160 | ||
| 3/4 | 23 | 0.62 | 3'x100' | 08.70 | 150 | ||
| 3/4 | 24 | 0.56 | 3'x100' |
07.10 140 |
|
Straight、Reverse twist Hexagonal Wire Mesh |
1 | 20 | 0.91 | 3'x100' | 14.50 | 160 | |
| 1 | 21 | 0.81 | 3'x100' | 11.50 | 150 | ||
| 1 | 22 | 0.71 | 3'x100' | 09.00 | 140 | ||
| 1 | 23 | 0.62 | 3'x100' | 06.80 | 130 | ||
| 1 | 24 | 0.56 | 3'x100' | 05.60 | 150 | ||
| 6/5 | 19 | 1.01 | 3'x100' | 15.00 | 170 | ||
| 6/5 | 20 | 0.91 | 3'x100' | 12.50 | 160 | ||
| 6/5 | 20 | 0.91 | 3'x100' | 12.50 | 160 | ||
| 6/5 | 21 | 0.81 | 3'x100' | 09.90 | 150 | ||
| 6/5 | 22 | 0.71 | 3'x100' | 07.60 | 150 | ||
| Reverse twist Hexagonal Wire Mesh | 3/2 | 18 | 1.20 | 3'x100' | 17.00 | 200 | |
| 3/2 | 19 | 1.01 | 3'x100' | 12.00 | 170 | ||
| 3/2 | 20 | 0.91 | 3'x100' | 09.70 | 160 | ||
| 3/2 | 21 | 0.81 | 3'x100' | 07.70 | 145 | ||
| 3/2 | 22 | 0.71 | 3'x100' | 06.00 | 140 | ||
| 2 | 18 | 1.20 | 3'x100' | 12.00 | 180 | ||
| 2 | 19 | 1.01 | 3'x100' | 08.50 | 170 | ||
| 2 | 20 | 0.91 | 3'x100' | 07.00 | 150 | ||
| 2 | 21 | 0.81 | 3'x100' | 05.50 | 145 | ||
| 2 | 22 | 0.71 | 3'x100' | 04.30 | 140 | ||
| 3 | 18 | 1.20 | 3'x100' | 08.80 | 170 | ||
| 3 | 19 | 1.01 | 3'x100' | 06.00 | 170 | ||
| 3 | 20 | 0.91 | 3'x100' | 05.00 | 160 |
