Appilcation
It widely used in Mine, Grain Field, Metallurgy, Building Materials, Chemical Industry, Ore-dressing, Colliery.
Working Principle
Controlled by a silicon controlled half-wave rectification circuit, the device adjusts the current of the electromagnetic coil to periodically generate electromagnetic force and drive the trough to vibrate. During the positive half-cycle, electromagnetic force pushes the trough backward and stores energy in the main spring. In the negative half-cycle, the spring releases energy and pushes the trough forward to create continuous vibration cycles. Driven by vibration, materials are thrown up and move forward along a parabolic trajectory. This design reduces direct friction between materials and the trough to lower wear. Operators can precisely adjust feeding speed and flow rate by changing excitation force or frequency.
Features
Electromagnetic head keeps stable amplitude and uniform feeding ,low power consumpution .
The electric controller can adjust vibrating force simply and conveniently.
The rubber spring keeps this feeder low noise when it is working .
The machine has simple structure ,no wearing part ,easy to maintain .
The feeder can be customized with cover and hopper ,fit for production line.
Welcome to contact with us.
