TF035HM 4M40 Turbocharger 49377-03101 49135-03300 Turbo for Mitsubishi Fuso Truck & Bus Canter Diesel With 4M40 Engine
US$ 50 - 100
MOQ: 1 Piece
Key Specifications
Get Latest Price
Brand Name:
Junfeng
Place of Origin:
Jiangsu, China
Model Number:
TF035HM
Payment & Shipping
Payment Methods:
Port of Shipment:
Huangpu
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
4M40 Turbocharger 49377-03031 49135-03101 Turbo for Mitsubishi Pajero IIUS$ 50 - 100MOQ: 1 Piece -
TD04 4D56 Turbo Charger 49177-02500 MD170563 49177-02510 for Mitsubishi Pajero II 2.5 TD With 4D56Q EngineUS$ 80 - 100MOQ: 1 Piece
-
RHF4H Turbo VB420088 1515A029 4D56 Turbocharger for Mitsubishi L200, W200 4D5CDI EngineUS$ 50 - 300MOQ: 1 Set
-
VT16 Turbo for MITSUBISHI L200 DC 2.5 4D56 5VX + H/L 2+2DR DBH DIE 1515A222 TurboUS$ 50 - 150MOQ: 1 Set
-
4M41 Turbo for Mistubishi Pajero 49135-03400 TurbochargerUS$ 50 - 250MOQ: 1 Set
Brand Name
Junfeng
Place of Origin
Jiangsu, China
Model Number
TF035HM
Warranty
3 Miles
TF035HM 4M40 Turbocharger 49377-03101 49135-03300 Turbo for Mitsubishi Fuso Truck & Bus Canter Diesel With 4M40 Engine
Product Description
| Part Number | 49135-03300 |
| Previous Version | 4913503300 |
| OE number | ME202879, ME190511 |
| Description | Mitsubishi FUSO Canter Diesel |
| CHRA | 49135-08000 (1401635906) $350.00 NEW IN STOCK, MADE IN USA |
| Turbo Model | TF035HM-12T-4 |
| Engine | 4M40 |
| Displacement | 2.8L, 2800 ccm |
| Fuel | Diesel |
| Bearing Housing | 49377-25200 (1401635460, 1401404470) $139.00 NEW IN STOCK |
| Turbine Wheel | 49135-30100 (Ind. 36.25 mm, Exd. 43.1 mm, 11 Blades) (1401635435, 1100016197) $125.00 NEW IN STOCK |
| Comp. Wheel | 49135-00016 (Ind. 56. mm, Exd. 43.25 mm, Trm 60, 6+6 Blades)(1401635426, 1200016262) $49.62 NEW IN STOCK |
| Back plate | 49135-00044 (49135-15405, 49173-22500) (1401635300) $15.94 NEW IN STOCK |
| Heat shield Number | 49135-19100 (49135-00020)(1401404342, 1401404340) (8 mm Deep) $14.64 NEW IN STOCK |
| Repair Kit | 49177-80410 (1401404755) $98.80 NEW IN STOCK |
| Turbine Housing | 49135-16401 |
| Compressor Cover | 49135-00083 |
| Actuator | 49135-18410 |
| Settings Waste gate (pressure) | 0.913 - 1.007 bar |
| Settings Waste gate (lift rod) | 1.00 mm |
| Replacement | 49135-03300, 49135-03301, 49135-03310 |
| Gasket (turbine inlet) | 210346 (Stainless Steel) $12.00 |
| Gasket (turbine outlet) | 210571 (Stainless Steel) $28.00 |
| Gasket (oil outlet) | 210243 (Gasket Paper) |
Application
Mitsubishi Delica with 4M40 Engine
Mitsubishi Fuso Truck & Bus Canter Diesel With 4M40 Engine
1971-72 DAF 55 With 4M40 Engine
Product Show
Material Description
Our Factory
Package
