Synthetic Forming Fabrics for Writing Printing Paper Making

Synthetic Forming Fabrics for Writing Printing Paper Making thumbnail-1
Synthetic Forming Fabrics for Writing Printing Paper Making photo-1
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
China
Material:
Forming fabrics
Supply Type:
In-Stock Items
Contact Supplier Request Quote Chat Now
Hebei Qianghua Mesh Industry Co.,Ltd
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin China
Material Forming fabrics
Supply Type In-Stock Items
Yarn Count 1

Synthetic forming fabrics for Writing printing paper making

Synthetic Forming Fabrics/Synthetic Forming Wire/Synthetic Forming Mesh



Aplication:

Used in the forming part of paper machine.

4-shed single layer Polyester forming fabric is standard type of polyester forming fabric in paper making, mainly used for producing cultural paper printing paper, packing paper and so on.

5-shed single layer Polyester forming fabric is suitable for making healthy, culture and packing papers etc.

8-shed single layer Polyester forming fabric is the most wear-resisting one in the single layer screen, which have long performance life, but mesh print is relatively deep. It is mainly used for copying the papermaking bag, craft paper, cardboard, corrugated paper and so on.

16-shed double and a half layer fabric is suitable for making quality printing paper, tissue paper and surface paper, inner paper and base paper of the board paper, etc;
Multi-shed three-layer polyester fabric is suitable for making quality printing paper, tissue paper and cigarette paper, etc.



Technical data of Synthetic Forming Fabrics

4-shed single layer

  Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

CXW27254

0.2

0.25

29.5-30.5

21.5-22.5

7000

CXW31204

0.18

0.2

34.5-35.5

27.5-28.5

6800

5-shed single layer

Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

CXW25275

0.22

0.27

27.5-28.5

18.5-19.5

7500

CXW27275

0.2

0.27

29.5-30.5

23-24

6800

8-shed single layer

Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

CXW25358

0.22

0.35

27.5-28.5

21.5-22.5

7800

CXW27458

0.20

0.40

29.5-30.5

19.5-20.5

7000

7-shed double layer

Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

56177

0.17

0.17/0.20/
0.20

60

48

5200

57177

0.17

0.17/0.20/
0.20

65.7

49.6

4550

8-shed double layer

Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

2C6208

0.15

0.16/0.19/0.19

68.5-69.5

51-52

6200

2C6408

0.15

0.18/0.20/0.20

70-71

52-53

5076

2C60188

0.18

0.19/0.20/0.20

66

49

4750

8-shed double and a half layer forming fabrics

Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

2B5008

0.17

0.13/0.18/0.32/0.32

55-56

48-49

6500

2B6408

0.15

0.13/0.18/0.20/0.20

70-71

52-53

5100

16-shed double and a half layer forming fabrics

Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

2B3616

0.25

0.20,0.30/0.50,0.50

39-40

38-39

7500

2B5616

0.17

0.13,0.20/0.35,0.35

63-64

56.5-57.5

5000

16-shed,20shed three layer forming fabrics

Model of fabrics

  Thread diameter  mm

  Density ( thread/cm)

  Air permeability
(m3/m2/h)

warp

weft

warp

weft

3WB3616

0.25/0.25

0.22,0.22/0.22/
0.55,0.55

40-41

38-39

6500

3WB5620

0.15/0.20

0.15,0.15/0.15/
0.25,0.25

63-64

60-61

6000

3WB6020

0.30/0.20

0.13,0.13/0.13/
0.25,0.25

69.5-70.5

71.5-72.5

5500



Are you looking for good manufacturer and supplier of forming fabrics?

Welcome to our factory.We are professional manufacturer of forming fabrics.

We have a wide range of forming fabrics.All forming fabrics quality is guaranteed. We also provide OEM service.

More information please click here.


Product Tags: Forming fabrics , Synthetic Forming Fabrics
