Home > Instruments & Meters > Meter for Electricity > Energy Meter & Power Meter > Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter

Name: Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter
Brand: Acrel
SKU: 165438025

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter thumbnail-1

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter thumbnail-2

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter thumbnail-3

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter thumbnail-4

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter thumbnail-5

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter photo-1

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter photo-2

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter photo-3

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter photo-4

Acrel ADL200 Single Total Active Energy Measure Din Rail Single Phase Electric Meter photo-5

US$ 35 - 35 MOQ: 1 Piece

Key Specifications

Get Latest Price

Brand Name:

Acrel

Place of Origin:

China

Model Number:

ADL200

Contact Supplier Request Quote Chat Now

Jiangsu Acrel Electrical Manufacturing CO.,LTD

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Brand Name Acrel

Place of Origin China

Model Number ADL200

Phase Single Phase

Output Voltage 220V

Operating Temperature -25℃~55℃

Dimensions 36mm*96 mm*70mm

Display Type Digital Only

Accuracy Class 1 class

Measuring Energy Range 000000.00~999999.99kWh

General

ADL100 din rail energy meter adopts DIN35mm din rail installation with LCD display,it can measure electric parameters and has energy pulse output, RS485 communication,which has the advantages of small size, high precision, good reliability and convenient installation.

Input voltage	Rated voltage	AC 220V
	Reference frequency	50Hz
	Power consumption
Input current	Basic current	10A,20A
	Maximum current	60A,100A
	Starting current	4‰Ib
	Consumption
Measurement performance	Accuracy of measuring	kWh Class 1
	Range of measuring	000000.00~999999.99kWh
Clock accuracy		≤0.5s/d
Active pulse	Pulse width	80±20ms
	Pulse constant	1600imp/kWh
Communication	Interface	RS485(A+、B-)
	Connection mode	Shielded twisted pair conductors
	Protocol	MOD BUS- RTU
Dimensions (Length × Width × Height)		88mm×36mm×70mm
Temperature	Work temperature	-25℃~55℃
	Storage Temperature	-40℃~70℃
Relative humidity		≤95%(No condensation)
Altitude
