ET-CGM95B low rpm 12v 24v pig rotisserie motor 3Nm
What Etonm motor offer? ETONM offers Mini DC motors and DC Gear motors:
- DC Voltage: from 1VDC to 30VDC
- Low Speed: from 0.1rpm to 1500rpm
- Torque: 0.1kg.cm to 400kg.cm
- Mini size: diameter from Φ6mm to Φ50mm
- Low noise
- Long lifetime
What is DC Gear Motor? DC Gear motor, is also called DC Geared Motor, Geared Dc Motor and gearhead motor or gearbox motor. It consists of a electric DC motor and a gearbox or gearhead; these gearheads are used to reduce the DC motor speed, while increase the DC motor torque. Therefore user can get lower speed and higher torque from gear motor.
| Type: |
ET-CGM95-B Robot Dc Gear Motor |
| Voltage: | 12V-230V |
| Input power: | 0.2-30W |
| Torque: | 3-600kg.cm |
| Design: | DC brushed gear motor |
speed: 0.7RPM, 1.5RPM, 1.6RPM, 2.8RPM, 3.1RPM, 3.7RPM, 4.2RPM, 6.4RPM, 8.1RPM, 11.7RPM, 16RPM, 22RPM, 30RPM, 43RPM, 58.8RPM, 82RPM, 111RPM, 160RPM, 219RPM, 423RPM, 577RPM, 594RPM, 810RPM
Range of reduction ratio: 37,60,66,86,162,265,315,594,651,973,1059
Application: Robotics Motor, Automatic Curtain Machine motor, cordless power tool, token, optical equipment, Remote Control Electric Curtain System, monitoring cameras, ticket selling machines, automatic energy saving bath.
we can customize the motor, if you have any question about the motor, please feel free to contact us, your inquiry will be welcomed.
| MODEL | VOLTAGE | NO LOAD | AT RATED LOAD | ||||
| OPERATION RANGE |
NOMINAL | SPEED | CURRENT | SPEED | CURRENT | TORQUE | |
| r/min | A | r/min | A | kg.cm | |||
| ET-CGM95A-12162 | 6.0-12.0 | 12.0 | 162 | ≤0.9 | 124 | ≤3.9 | 19 |
| ET-CGM95A-12100 | 6.0-12.0 | 12.0 | 100 | ≤0.9 | 76 | ≤3.9 | 30 |
| ET-CGM95A-1270 | 6.0-12.0 | 12.0 | 70 | ≤0.9 | 52 | ≤3.9 | 43 |
| ET-CGM95A-1237 | 6.0-12.0 | 12.0 | 37 | ≤0.9 | 27 | ≤3.9 | 74 |
| ET-CGM95A-1223 | 6.0-12.0 | 12.0 | 23 | ≤0.9 | 16 | ≤3.9 | 122 |
| ET-CGM95A-1219 | 6.0-12.0 | 12.0 | 19 | ≤0.9 | 13.5 | ≤3.9 | 145 |
| ET-CGM95A-1210 | 6.0-12.0 | 12.0 | 10 | ≤0.9 | 7 | ≤3.9 | 200* |
| ET-CGM95A-1209 | 6.0-12.0 | 12.0 | 9 | ≤0.9 | 6 | ≤3.9 | 200* |
| ET-CGM95A-1206 | 6.0-12.0 | 12.0 | 6 | ≤0.9 | 4 | ≤3.9 | 300* |
| ET-CGM95A-125.6 | 6.0-12.0 | 12.0 | 5.6 | ≤0.9 | 3.6 | ≤3.9 | 300* |
|
Remarks: 1. Gearbox Shaft can be made with double shaft, shaft dimension can be customized. 2. The Voltage can be 6VDC, 12VDC, 24VDC; The DC Motor's speed is adjustable.(the Above data list can also be made be the same at 24VDC.) 3. This gearbox can matched with other DC Motors. | |||||||
