China Bearing 6204RS Deep Groove Ball Bearing for Hardware

China Bearing 6204RS Deep Groove Ball Bearing for Hardware thumbnail-1
China Bearing 6204RS Deep Groove Ball Bearing for Hardware thumbnail-2
China Bearing 6204RS Deep Groove Ball Bearing for Hardware thumbnail-3
China Bearing 6204RS Deep Groove Ball Bearing for Hardware thumbnail-4
China Bearing 6204RS Deep Groove Ball Bearing for Hardware thumbnail-5
China Bearing 6204RS Deep Groove Ball Bearing for Hardware thumbnail-6
China Bearing 6204RS Deep Groove Ball Bearing for Hardware photo-1
China Bearing 6204RS Deep Groove Ball Bearing for Hardware photo-2
China Bearing 6204RS Deep Groove Ball Bearing for Hardware photo-3
China Bearing 6204RS Deep Groove Ball Bearing for Hardware photo-4
China Bearing 6204RS Deep Groove Ball Bearing for Hardware photo-5
China Bearing 6204RS Deep Groove Ball Bearing for Hardware photo-6
US$ 0.35 - 0.4 MOQ: 10 Sets
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Model Number:
6204RS
Number of Row:
Single Row
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao/guang zhou
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Model Number 6204RS
Number of Row Single Row
Seals Type open
Precision Rating p0 p6 p5 p4 p2
Bore Size 20, 20.001

  china bearing 6204RS deep groove ball bearing for hardware

Product Description





These ball bearings are made of high quality Chrome Steel and are pre-lubricated with grease from the factory and are available in both RS (Rubber Seals) and ZZ (Metal Shields) configurations. The 6204-2RS-12 and 6204-ZZ-12 is a 3/4"bore ball bearing that is found in many applications. The 6204-2RS-12 ball bearing has two contact rubber seals, one on each side of the ball bearing. The 6204-ZZ-12 bearing has two non-contact metal shields, one on each side of the ball bearing. If your application requires a 6204-12 ball bearing with only one seal or shield you can simply remove one of the shields or seals. This 3/4"bore ball bearing is a high quality product and can operate efficiently in many demanding applications.



Quality Benefits Include



·Textured Buna N Nitrile seals
·Wide temperature range Chevron SRI-2 (-20° to +350°F) lubrication
·Passes Noise Vibration Standard for low noise
·Designed for many types of applications
·Matched ABMA grade precision balls for roundness
·Finely honed super finished raceways for long life and low noise
·Meet or exceed ABEC 1 tolerances for high quality level
·Bulk packaged



6204RS Sealed Ball Bearing
20mm x 47mm x 14mm





6204RS Sealed Ball Bearings, metric standard bearing 6204RS has rubber Seals to protect the bearing from dust or any possible contamination, 6204RS bearings are lubricated with grease, 6204RS is single row, radial, deep groove ball bearings, the chrome steel balls are separated by a steel cage, 6204RS has the dimensions 20mm ID x 47mm OD x 14mm wide, here is the 6204RS catalog:

  • Item: 6204RS Ball Bearing
  • Type: Deep Groove Ball Bearing Design
  • Standard: Metric
  • Quality: Standard Precision
  • Inner and Outer Rings Material: Chrome Steel
  • Balls Material: Chrome Steel
  • Cage Material: Steel
  • Band: VXB
  • Closures: Rubber Sealed
  • Lubrication: Self Lubricated (Grease)
  • 6204RS Size: 20mm x 47mm x 14mm
  • Inner Diameter: 20mm (Bore/ID)
  • Outer Diameter: 47mm (OD)
  • Width: 14mm
  • Quantity: One Bearing



model  number

New Items Old Items Specifications(dxDxB) Weight/kg
6200 200 10x30x9 0.032
6201 201 12x32x10 0.0365
6202 202 15x35x11 0.0431
6203 203 17x40x12 0.065
6204 204 20x47x14 0.11
6205 205 25x52x15 0.134
6206 206 30x62x16 0.218
6207 207 35x72x17 0.284
6208 208 40x80x18 0.37
6209 209 45x85x19 0.428
6210 210 50x90x20 0.462
6211 211 55x100x21 0.59
6212 212 60x110x22 0.8
6213 213 65x120x23 1.01
6214 214 70x125x24 1.34
6215 215 75x130x25 1.16
6216 216 80x140x26 1.39
6217 217 85x150x28 1.92
6218 218 90x160x30 2.19
6219 219 95x170x32 2.61
6220 220 100x180x34 3.23
6221 221 105x190x36 3.66
6222 222 110x200x38 4.29
6224 224 120x215x40 5.16
6226 226 130x230x40 6.19
6228 228 140x250x42 9.44

6000 Series

N0.

Bore

 O.D Width Chamfer Load Rating Maximuum Seed Weight

mm

 mm mm mm

Dynamic

Cr

Static

Cor

Grease

r/min

Oil

r/min

 Kg/pcs
604 4 12 4 0.2 0.97 0.36 36000 44000 0.0021
605 5 14 5 0.2 1.33 0.505 32000 40000 0.0035
606 6 17 6 0.3 2.19 0.865 30000 38000 0.006
607 7 19 6 0.3 2.24 0.91 28000 36000 0.008
608 8 22 7 0.3 3.35 1.4 26000 34000 0.012
609 9 24 7 0.3 3.4 1.45 24000 32000 0.014
6000 10 26 8 0.3 4.55 1.96 22000 30000 0.019
6001 12 28 8 0.3 5.1 2.39 19000 26000 0.021
6002 15 32 9 0.3 5.6 2.83 18000 24000 0.03
6003 17 35 10 0.3 6.8 3.35 17000 22000 0.039
6004 20 42 12 0.6 9.4 5.05 15000 19000 0.069
6005 25 47 12 0.6 10.1 5.85 14000 18000 0.08
6006 30 55 13 0.6 13.2 8.3 12000 15000 0.116
6007 35 62 14 1.0 16 10.3 10000 14000 0.115
6008 40 68 15 1.0 16.8 11.5 8000 11000 0.19
