Deep groove ball bearing 6224 C3 bearing size120X215X40mm
Descriptions of 6224/C3 bearing
6224 bearings are widely used in industrial drive, agriculture, compressors, motors and generators, construction, industrial fan, industrial transmission and other fields. 6224 bearings can ensure high quality for more than 80% raw material of 6224 bearings provided by the steel plant.Explorer series bearing of 6224 bearings are better than any brand bearings currently in bearing performance , lifetime, design, and the use of performance. Explorer series bearings of 6224 bearings have more advantages ,such as higher meet rated , lower noise, reducing warranty costs greatly, increasing running time of the machine .
6224/C3 bearing details
| Boundary dimensions(mm) | Basic load ratings(kN) | Limiting speeds(rpm) | Mass(Kg) | Bearing Number | |||||
| d | D | B | rs min | Cr | Cor | Grease | Oil | (Approx.) | CLUNT |
| 120 | 215 | 40 | 2.1 | 155 | 131 | 2,900 | 3,400 | 5.15 | 6224 |
Specifications Met
| Main bearing dimensions | DIN 625-1 |
| Basic dynamic load ratings | DIN ISO 281 |
| C3 radial internal clearance | DIN 620-4 (ISO 5 753) |
| Shaft and housing tolerances | ISO 286 |
| Through-hardening steel for inner and outer rings | ISO 683-17 |
| Steel strip for cage | EN 10139, SAE J403 |
| Load carrying capacity and life | DIN ISO 281 Appendix 1 |
| System for creating part numbers for rolling bearings | DIN 623-1 |
6224/C3 bearing Features
6224 bearing deep groove ball bearings are mainly used in centrifuges, axle bolts, CNC punching, cylindrical gear reducer, electric vehicle motors, valves, CNC cutting, electrodialysis equipment, electrical instrumentation, automotive lamps other equipment
Deep groove ball bearings are versatile, self-retaining bearings with solid outer rings, inner rings and ball and cage assemblies.
These products, which are of simple design, robust in operation and easy to maintain, are available in single and double row designs and in open and sealed variants. Due to the manufacturing processes used, open bearings can have turned recesses in the outer ring for seals or shields. Due to their low frictional torque, deep groove ball bearings are suitable for high speeds.
Deep groove ball bearing catalog
| TYPE | Overall dimension | Basic Load | Limiting Speeds | Weight | |||||
| d | D | B | rsmin | (Cr) | (Cor) | Grease | Oil | ||
| mm | KN | rpm | KG | ||||||
| 625 | 5 | 16 | 5 | 0.3 | 1.45 | 0.74 | 32000 | 40000 | 0.005 |
| 626 | 6 | 19 | 6 | 0.3 | 2.34 | 0.885 | 34000 | 40000 | 0.008 |
| 627 | 7 | 22 | 7 | 0.3 | 3.35 | 1.4 | 32000 | 37000 | 0.014 |
| 628 | 8 | 24 | 8 | 0.3 | 4 | 1.59 | 31000 | 36000 | 0.016 |
| 629 | 9 | 26 | 8 | 0.3 | 4.45 | 1.95 | 30000 | 35000 | 0.019 |
| 6200 | 10 | 30 | 9 | 0.6 | 5.1 | 2.38 | 24000 | 30000 | 0.032 |
| 6201 | 12 | 32 | 10 | 0.6 | 6.82 | 3.05 | 22000 | 27000 | 0.035 |
| 6202 | 15 | 35 | 11 | 0.6 | 7.65 | 3.72 | 19000 | 24000 | 0.045 |
| 6203 | 17 | 40 | 12 | 0.6 | 9.58 | 4.78 | 17000 | 21000 | 0.064 |
| 6204 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 14000 | 18000 | 0.103 |
| 6205 | 25 | 52 | 15 | 1 | 14 | 7.88 | 12000 | 16000 | 0.127 |
| 6206 | 30 | 62 | 16 | 1.1 | 19.5 | 11.5 | 10000 | 13000 | 0.202 |
| 6207 | 35 | 72 | 17 | 1.1 | 25.5 | 15.2 | 9000 | 11000 | 0.288 |
| 6208 | 40 | 80 | 18 | 1.1 | 29.5 | 18 | 8200 | 10000 | 0.368 |
| 6209 | 45 | 85 | 19 | 1.1 | 31.5 | 20.5 | 7600 | 9300 | 0.416 |
| 6210 | 50 | 90 | 20 | 1.1 | 35 | 23.2 | 7000 | 8600 | 0.463 |
| 6211 | 55 | 100 | 21 | 1.5 | 46.3 | 29 | 6300 | 7500 | 0.61 |
| 6212 | 60 | 110 | 22 | 1.5 | 47.5 | 32.5 | 6000 | 7000 | 0.78 |
About us
1.Staff mission: to develop, innovation, cooperation and good faith.
2,Company's goals: a hundred years the name Enterprise, the industry fresh air.
3,Staff objectives: Choi-chi, with a minor, win-win progress.
4,Business philosophy: science and technology, quality, service, win-win situation.
5,Service spirit: Dissemination of cutting-edge technology together to create wealth.
6,Staff spirit: innovation, cooperation, sincerity and dedication.
7,Development strategy: the internationalization of enterprises to enter the brand name.
8,The core concept: the market conception of qualified personnel, learning concept
Main bearing products
Deep groove ball bearing: 6000series, 6100series, 6200series, 6300series, 6400 series, 6800 series,6900 series, etc.
Angular contact ball bearing: 7100series, 7200series, 7300series, 7400series, etc.
Taper roller bearing: 30000series, 31000series, 32000series, 33000 series.
Spherical roller bearing: 20000series, 21000series, 22000series, 23000series.
Cylindrical roller bearing: N series, NU series, NJ series, etc.
Pillow block bearing: UC series, UCP series, UCF series, UCFL series.
Self aligning ball bearing: 1200series, 1300series, 2200series, 2300series.
Needle Roller Bearing
Sliding bearing
Slewing Bearing
Rod End Joint Bearing
Ceramic Bearing
Bearing Accessories
Excellent and high quality control
1.Rich Inventory to mostly shorten the delivery time
2.Package design as clients' requirement
3.Providing the most economic carriage solution
4.OEM manufacturing supplied(Including clients' own brand)
5.Produce as drawings provided by clients
6.Design drawings as specifications and applications
7.Preferred payment term:T/T;Paypal;Western Union
Through the organized quality assurance system, our company strive to accomplish
a. Fullfill it's commitment towards quality products,
b. Efficient delivery time, generally 3-7 days,
c. Provide immediate and efficient response to customers' feedback,
d. Germany imported technology, CNC machines.
e. Provide OEM&Customized service.
Processing flow
