Small v Structure Deep Groove Ball Bearing 6308

Small v Structure Deep Groove Ball Bearing 6308 thumbnail-1
Small v Structure Deep Groove Ball Bearing 6308 thumbnail-2
Small v Structure Deep Groove Ball Bearing 6308 thumbnail-3
Small v Structure Deep Groove Ball Bearing 6308 thumbnail-4
Small v Structure Deep Groove Ball Bearing 6308 thumbnail-5
Small v Structure Deep Groove Ball Bearing 6308 thumbnail-6
Small v Structure Deep Groove Ball Bearing 6308 photo-1
Small v Structure Deep Groove Ball Bearing 6308 photo-2
Small v Structure Deep Groove Ball Bearing 6308 photo-3
Small v Structure Deep Groove Ball Bearing 6308 photo-4
Small v Structure Deep Groove Ball Bearing 6308 photo-5
Small v Structure Deep Groove Ball Bearing 6308 photo-6
US$ 3 - 4 MOQ: 10 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Model Number:
6308
Number of Row:
Single Row
Contact Supplier Request Quote Chat Now
Jinan Kelunte Bearing Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Model Number 6308
Number of Row Single Row
Seals Type 6308
Precision Rating P0 P4 P5
Bore Size 39.9, 40

small v structure deep groove ball bearing 6308



small v structure deep groove ball bearing 6308 specification :



Product Name: deep groove ball bearing 6308-2RS
Supply Ability: 500,00pcs/mnth
Specifications 40mm*90mm*23mm
Price Term: FOB
Port of loading: qingdao
Minimum Order 1000pcs



 small v structure deep groove ball bearing 6308small v structure deep groove ball bearing 6308small v structure deep groove ball bearing 6308small v structure deep groove ball bearing 6308small v structure deep groove ball bearing 6308small v structure deep groove ball bearing 6308



 the advantage of  small v structure deep groove ball bearing 6308 :



6308-2RS Ball Bearings, the 6308RS inner diameter is 40 mm, 6308-2RS outer diameter is 90 mm and the 6308RS width is 23mm, 6308RS is a popular size that could be used in many applications, 6308RS Bearings are made of Chrome Steel,6308-2RS can rotate up to 5300 rpm,6308-2RS bearing has 2 Blue Rubber Seals to protect the bearing from dust or any possible contamination,6308-2RS bearings are pre-lubricated with grease.



  • Item: 6308-2RS Chrome Steel - Radial Deep Groove Ball Bearings
  • Size: 40mm x 90mm x 23mm 6308-2RS
  • Dimensions: 40*90*23 mm/Metric
  • Dynamic load rating Cr: 40,500 N
  • Static load rating Cor: 24,100 N
  • Limiting Speed:
    • Grease Lubrication: 5,300 RPM
  • ID (inner diameter)/Bore=40mm
  • OD (outer diameter)=90mm
  • Width/Height/thickness=23mm
  • Equal: 6308-2RS1 & 6308-2RZ
  • 6308RS Type: Deep groove ball bearings
  • Closures: 2 Rubber Seals 6308RS
  • 6308-2RS Lubrication: Self Lubricated (Grease)
  • Quantity: One 6308RS
  • MARKING: 6308RS
  • Equal: 6308RS1, 63082RS



  Deep groove ball bearing is suitable for high speed running, and very durable, need not often maintenance. These bearing small friction coefficient, high limit speed, size range and diverse in form, used in precision instruments, low noise motors, automobiles, motorcycles and general machinery and other industries, is the most widely used type of bearings in machinery industry. Mainly bear radial load, also can withstand a certain amount of axial load.
Deep groove ball bearing has simple structure, easy to use, is the production batch, the biggest range is the most widely used type of bearings. Widely used in automobiles, household appliances, machine tools, motors, pumps, agricultural machinery, textile machinery, and many other fields. Its output accounted for over 70% of the total production of the bearing, it is the highest yield in China, the most commonly used and the price is the cheapest kind of bearings.





Material handling machinery, grinding machinery agricultural machinery, mining machinery, textile machinery, fluid machinery, bionic machinery casting equipment, power equipment, lifting equipment, refrigeration equipment, separation equipment and
molding and packaging equipment.
Agricultural machinery: tractors, planters, harvesting machinery, etc.
b) Heavy-duty mining machinery: metallurgical machinery, mining machinery, lifting machinery, loading and unloading machinery, industrial vehicles, cement equipment, etc.
c) Construction Machinery: forklifts, earth moving machinery, compaction machinery, concrete machinery, etc.
d) The general petrochemical machinery: oil drilling machinery, oil refining machinery, chemical machinery, pumps, fans, valves, gas compressors, refrigeration and air conditioning machinery, paper machinery, printing machinery, plastic processing machinery, pharmaceutical machinery, etc.
e) Electrical machinery: power generation equipment, transformers, motors, low voltage switch, wire and cable, battery, welding machines, household appliances, etc.
f) Machine tools: metal cutting machine tools, forging machinery, foundry machinery, woodworking machinery, etc.
g) Car: truck, road, bus, car, modified car, motorcycle ,etc.
h) Instrumentation: Automation Instrumentation, electrical, instrumentation, optical instruments, composition analyzers, automotive instrumentation, electrical materials and equipment, audio-visual equipment, cameras, etc.



the catalogue of small v structure deep groove ball bearing 6308 distributors :



Bearing NO. I.D O.D W Load Rating(KN) Steel Ball Parameter Max Speed Weight
Kg
d D B Dynamic Static NO. Size Grease Oil
mm inch mm inch mm inch Cr Cor mm r/min r/min
6300 10 0.3937 35 1.3779 11 0.4331 8.2 3.5 6 7.14 23000 27000 0.053
6301 12 0.4724 37 1.4567 12 0.4724 9.7 4.2 6 7.94 20000 24000 0.060
6302 15 0.5906 42 1.6535 13 0.5118 11.4 5.45 7 7.94 17000 21000 0.082
6303 17 0.6693 47 1.8504 14 0.5512 13.5 6.55 7 8.73 16000 19000 0.120
6304 20 0.7874 52 2.0472 15 0.5906 15.9 7.9 7 9.53 14000 17000 0.140
6305 25 0.9843 62 2.4409 17 0.6693 21.2 10.9 7 11.5 12000 14000 0.230
6306 30 1.1811 72 2.8346 19 0.748 26.7 15 8 12 10000 12000 0.350
6307 35 1.3779 80 3.1496 21 0.8268 33.5 19.1 8 13.5 8800 10000 0.460
6308 40 1.5748 90 3.5433 23 0.9055 40.5 24 8 15.1 7800 9200 0.630
6309 45 1.7716 100 3.937 25 0.9843 53 32 8 17.5 7000 8200 0.830
6310 50 1.965 110 4.3307 27 1.063 62 38.5 8 19.1 6400 7500 1.050
6311 55 2.1653 120 4.7244 29 1.1417 71.5 45 8 20.6 5800 6800 1.350
6312 60 2.362 130 5.1181 31 1.2205 82 52 8 22.2 5400 6300 1.700
6313 65 2.559 140 5.7087 33 1.2992 92.5 60 8 24 4900 5800 2.100
6314 70 2.7559 150 5.9055 35 1.378 104 68 8 25.4 4600 5400 2.500
6315 75 2.9528 160 6.2992 37 1.4567 113 77 8 27 4300 5000 3.000
6316 80 3.1496 170 6.6929 39 1.5354 123 86.5 8 28.6 4000 4700 3.600
6317 85 3.3465 180 7.0866 41 1.6142 133 97 8 30.2 3800 4500 4.250
6318 90 3.5433 190 7.4803 43 1.6929 143 107 8 32 3600 4200 4.900
6319 95 3.7402 200 7.874 45 1.7717 153 119 8 34 3300 3900 5.650
6320 100 3.937 215 8.2677 47 1.8504 173 141 8 36.5 3200 3700 7.000
Company Information

Jinan Kelunte Bearing Company is located in the capital city of Shandong Province of China, we're China professional bearing manufacturer and we have engaged in Manufacturing and exporting for more than 20 years. Our main products including deep groove ball bearings, taper roller bearings, pillow block bearings, angular contact ball bearings, wheel hub bearings, clutch release bearings and so on. small v structure deep groove ball bearing 6308





Customer Friendship

small v structure deep groove ball bearing 6308small v structure deep groove ball bearing 6308

FAQ

 1. How long is your delivery term?

Our standard product delivery term is normally 30 days. A new product development cycle is 60 days in normal. Under normal circumstances, there are standing stock for regular types. You can email us to learn more details.

2. Where is your port of shipment located?

Our main port of shipment is Qingdao port, and we may operate at other ports if required by the customer.

3. I couldn’t find a design to fit my application in your catalog. Can you help me design a bearing?

Yes, technical expertise is available to assist you with engineering design for custom products. Available options include, but are not limited to, custom rings, retainers, balls, shields, lubricants, and packaging. We look forward to working with you to satisfy your rotary motion requirements.

4. Is optional lubrication provided?

We can offer a wide range of oils and greases for a variety of applications. Please contact our engineer for technical assistance with any special requirements.

5. What is the difference between using a shield or a seal as a ball bearing closure?

Shields or seals are often installed to retain lubricant and to prevent contamination from entering the bearing. While a shield contacts the outer ring and does not come in contact with the inner ring, the seal generally comes in contact with both the inner and outer rings. Torque or drag is lower with a shield than with a seal. Alternately, the seal provides a higher degree of protection from contamination. Shields and seals are available in a variety of materials and configurations.

CLUNT developed a serious of sealing methods for different applications. Please contact a CLUNT engineer for technical assistance with any special requirements.

Any questions, please feel free to contact us!
