high quality deep groove ball bearing 6030 bearing price list
Specifications
| Bore diameter: | 150 mm | Static load capacity: | 125 kN |
|
| Outside diameter: | 225 mm | Precision rating: | ABEC 1 (ISO Class Normal) |
|
| Overall width: | 35 mm | Finish/coating: | Uncoated |
|
| Bore type: | Round |
Cage material: | Steel |
|
| Closure type: | Open |
Outer ring width: | 35 mm |
|
| Row type & fill slot: | Single Row Non-Fill Slot |
Fillet radius: | 2 mm |
|
| Snap ring included: | Without Snap Ring |
Maximum rpm: | 3800 RPM |
|
| Internal clearance: | C0 |
Series: | 60 |
2.Application
Brands :
CLUNT
Sizes :
6000 series, 6200 series, 6300 series, 6400 series, 6800 series, 6900 series, 16000 series
Carbon steel ball bearings
Stainless steel ball bearings W series
Chrome steel (Gcr15) ball bearings
Ball bearings for high temperature work surroundings
Z, ZZ, RS, 2RS, RZ, 2RZ, RW, 2RW sealed types are available
Features:
1) Deep groove ball bearings mainly take radial load as well as take moderate axial load
2) With less coefficient of friction, high limiting speed, large size range and various structure
3) They are suitable of precision instruments, low noise motors, automobiles, motorcycles, and other common machinery
4) A widely used type of bearings in machinery industry
Applications:
16032 ball bearing Suitable for very high rotating speeds; Well suited for medium high radial and axial load. Widly used in Electric Motors,General Machinery such as Compressors, pumps, gearboxes and fans, Automotive,Electrical application,etc..
3.16000 Series Deep Groove Ball Bearing For Your Reference
16001 16002 16003 16004 16005 16006 16007 16008 16009 16010 16011 16012 16013 16014 16015 16016 16017 16018 16019 16020 16021 16022 16024 16026 16028 16030 16032 16034 16036 16038 16040 16044 16048 16052 16056
We can also supply these Deep Groove Ball Bearing series:
6000 sereis, 6200 series, 6300 series, 6400 series, 6800 series, 6900 series, MR series, MF series, R series
Welcome your inquiry!
Packing &Delivery
Jinan Kelunte Bearing Co., Ltd. is a professional deep groove ball bearing manufacturer and is engaged in the imported bearings.Our company is engaged in the imported bearings,company's main imported Roller Bearing,Ball Bearing,deep groove ball bearings,taper roller bearings,angular contact ball bearings,Pillow Block Bearing etc.
