CNI 150mW 593.5nm DPSS Orange Laser Module
APPLICATION:
It is used in collimation, laser medical treatment, scientific experiment, optical instrument, etc.
SPECIFICATIONS:
Wavelength (nm) |
593.5±1 |
||
Output power (mW) |
>50, 60, 80, …, 150 |
||
Transverse mode |
TEM00 |
||
Operating mode |
CW |
||
Power stability (rms, over 4 hours) |
<3%, <5%, <10% |
||
Warm-up time (minutes) |
<10 |
||
M2 factor |
<1.5 |
||
Beam divergence, full angle (mrad) |
<2. 0 |
||
Beam diameter at the aperture (mm) |
~3. 0 |
||
Beam height from base plate (mm) |
45 |
||
Polarization ratio |
>100:1 |
||
Pointing stability after warm-up (mrad) |
<0.05 |
||
Operating temperature (°C) |
10~35 |
||
Power supply (89-264VAC) |
PSU-H-LED |
PSU-H-FDA |
PSU-H-OEM |
Modulation option |
TTL on/off, 1Hz-1KHz, 1KHz-10KHz, 10KHz-30KHz; and Analog modulation option |
||
Expected lifetime (hours) |
10000 |
||
Warranty period |
1 year |
||
Orange laser
Laser Head
PSU-H-LED Power supply
PSU-H-FDA Power supply
