SZ680/SZ780 series stereo zoom usb micoscop
Excellent Technology And Quality
- High resolution, large depth of field, excellent color restoration and contrast.
- Operation comfortable(manufactured by high-precision machine, excellent assembly technology ).
- High- end material(PC resin cover, aluminium alloy ,copper alloy parts, austenite stainless steel driving parts).
International Level Appearance Design
- Elegant shape , high-end and integrated appearance design, comfortable operation.
Various Accessories,Complete Function.
- Different video output connectors, built-in digital image model.
- Illumination optional: LED, halogen lamp, cold light source etc. (100V-240V wide voltage input).
- Various professional stands and operating attachments.
Main Technical Specification
Model |
SZ680 |
SZ780 |
Objectives Zoom Range |
0.68X-4.7X |
0.66X-5.1X |
Zoom Ratio |
1 : 6.8 |
1 : 7.8 |
Field Diameter (mm) |
Φ23 |
Φ24 |
Working Distance (mm) |
110 |
110 |
Stereo Angle ( °) |
12 |
12 |
Viewing Angle ( °) |
35 |
35 |
Interpupillary Adjustable Distance (mm) |
50-75 |
50-75 |
Video Output Distribution |
100% |
100% |
Guide Rail Stand Focusing Distance (mm) |
80 |
|
Pillar Stand Focusing Distance (mm) |
115 |
|
SZ780 Series Objective & Eyepiece Parameter List (0.66×-5.1×)
Additional Objective |
0.5X |
1X(built-in) |
2X |
|
W.D |
189mm |
110mm |
36mm |
|
10XEyepiece/Φ23mm |
Magnification |
3.4~23.5 |
6.8~47 |
13.6~94 |
Field dia. (mm) |
67.65~9.79 |
33.82~4.89 |
16.91~2.46 |
|
20XEyepiece/Φ12mm |
Magnification |
6.8~47 |
13.6~94 |
27.2~188 |
Field dia.(mm) |
35.294~5.11 |
17.65~2.55 |
8.82~1.28 |
|
SZ680/780 Series Zoom Stereo Microscope General Layout Diagram
Items |
SZ680BP |
SZ680B2L |
SZ780BP |
SZ780B2L |
|
|
Main Body (1X objective built in) |
Binocular |
o |
o |
o |
o |
Trinocular |
x |
x |
x |
x |
|
Digital Head |
x |
x |
x |
x |
|
10XEyepiece/Φ23mm |
oo |
oo |
|
|
|
10XEyepiece/Φ24mm |
|
|
oo |
oo |
|
20XEyepiece/Φ12mm |
xx |
xx |
xx |
xx |
|
0.5X/2X Objective |
x |
x |
x |
x |
|
Focusing unit |
o |
o |
o |
o |
|
No light |
o |
|
o |
|
|
Reflecting 3W LED |
|
o |
|
o |
|
Transmitting 3W LED |
|
o |
|
o |
|
Black & white Plate |
o |
o |
o |
o |
|
Glass Plate |
|
o |
|
o |
|
Arm stand |
o |
o |
o |
o |
|
Pillar stand |
x |
x |
x |
x |
|
Base (330×300mm) |
o |
o |
o |
o |
|
C-mount 0.5X, 1X |
x |
x |
x |
x |
|
Adaptor for digital photo camera |
x |
x |
x |
x |
|
Two dimensional travelling table |
x |
x |
x |
x |
|
Single pole Universal Stand |
x |
x |
x |
x |
|
Note:"o" In Table Is Standard Outfits, "x" Is Optional Accessories.
