Universal Static Load Anchorage Testing Machine
Small MOQ:
we accept small quantity order to supports our cooperation.
Excellent quality with competitive price:
All our products are made in China and with competitive price.
OEM / ODM service:
We can offer OEM & ODM service.
It is a high-precision material testing equipment; It adopts hydraulic power source drive, electro-hydraulic servo control technology, computer data acquisition and processing, closed loop control and automatic detection.It consists of test host, main oil source (Hydraulic power source), mobile oil source (pre-tightening oil source), protective box composed of four parts, the maximum test force 6500kN.
| Model | JZSYJ-6500A |
Maxmum test force |
6500KN |
Accuracy class |
1 Class |
Relative error of indication |
±1% |
Effective measurement range |
1%-100%F·S(full range regardless of file) |
Deformation of indication relative error |
±1% |
Deformation measurement resolution |
0.001mm |
Displacement control range |
0-200 mm |
Force, deformation, displacement to maintain control |
2%-100%F·S |
Holding time |
≥24h |
Piston stroke |
200mm |
Tensile distance |
≥3400mm |
Testing range |
1~24 hole Anchors static load performance |
Power |
4.0KW |
Dimension for main |
3300x800x1000mm |
Dimension for oil source |
1100x800x900mm |
Oil source weight |
300Kg |
Weight |
4800Kg |
We has been in business manufacturing and distributing tools and equipment for valve seat reconditioning and valve reconditioning.
Our product is the valve seat cutter and boring Cutters. Seat cutters are almost standard equipment in any machine shop that services four-stroke engines - whether the work is small engine repair, automotive high performance, routine motorcycle maintenance, or heavy duty engine rebuilding. We believe that our product has been so popular for one simple reason: it offers value. It's extremely easy to use, is accurate enough to be the tool of choice for high performance engine work, and it doesn't require a huge investment.
If you have any other requirements,please contact us, we can customize according your demand.
We can ship By EMS,TNT,DHL and others ( door to door)
We be 24 hours online,if you have any questions,kindly contact us freely.
