1.Titanium rod filter core performance:
1) uniform structure, narrow aperture distribution, high separation efficiency.
2,) high porosity, small filtration resistance, high permeability efficiency.
3, )high temperature resistance, generally can be normally used below 280℃.
4,) good chemical stability, acid and alkali corrosion resistance, with oxidation resistance.
5,) no particles off, do not make the original solution form secondary pollution, in line with the requirements of food hygiene and pharmaceutical GMP.
6,) good mechanical properties, pressure filter can be pumped filter, simple operation.
7, )Low differential pressure, small footprint, large flow.
8,) anti-microbial ability is strong, does not work with microorganisms.
9,) forming process is good, the overall length of no welding up to 1000 mm.
10,) online regeneration, easy to clean, long service life (generally several times of the membrane filter element)
2. The main parameters of titanium rod filter element
Filtration precision: 0.22~100μm Porosity: 28~50% Compressive strength: 0.5~1.5MPa Temperature resistance: 280℃ (wet state) Maximum working pressure difference: 0.6MPa
3.Application field of titanium rod filter element
Titanium rod filter element with its unique performance, can be widely used in the pharmaceutical industry, water treatment industry, food industry, biological engineering, chemical industry, petrochemical, metallurgical industry and gas purification field. It is a kind of new material with wide development prospect. Typical uses include:
1,) pharmaceutical industry, large infusion, small injection, eye drops, oral liquid in the concentrated distribution link of the decarbonization filtration and sparse distribution link before the terminal filtration security filtration.
2.) Removal of impurities in the production process of API, removal of carbon filtration and fine filtration of materials.
3, )water treatment industry in the ultrafiltration, RO, EDI system security filtration, ozone sterilization after filtration and ozone aeration.
4. )Clarification and filtration of beverage, liquor, beer, vegetable oil, mineral water, soy sauce and vinegar in food and beverage.
5,) the chemical industry of liquid products, liquid raw materials, pharmaceutical intermediates of decarbonization filtration and precision filtration, ultra-fine fine body, catalytic agent filtration and recovery, precision filtration after resin adsorption and system heat conduction oil, material in addition to miscellany filtration, catalytic gas purification, etc.
6, )oil field reflux water filtration, seawater desalination field before the reverse osmosis security filtration.
7, )the dye industry of high temperature decharring, dewhite soil filtration.
8, )gas purification steam, compressed air, catalyst filtration.
