Step Down Transformer Connection
Step down transformer is transferring the higher voltage of input end to lower ideal voltage so that the voltage can be stepped down.
Frequency characteristic: low-frequency; phase number of power supply: single phase
Iron core figure: E Methods for cooling: dry-type Iron core figure: centrifugal The number of winding: duplex winding The way of dampproof: open-type
Type of cooling: naturally air-cooled
Outline structure: vertical electricity
Pressure ratio: 220/110(v)
Efficiency(η): 95
Rated power: 50-10000(KVA)
Input end voltage of step down transform: 460V, 380V, 220V, 400V.
Outlet-voltage: 380V, 220V, 110V, 36V, 24V.
Principle of control: Auto-induction voltage-reduced starting is a starting method to reduce voltage of motor end by autotransformer. Autotransformer can get different outlet-voltage from two sets of taps( 80% and 50% of common supply voltage), when it starts, one set of tap will use 65 percent tap to connect with loop of electromotor. When its speed of rotate is close to rated speed, remove autotransformer so that electromotor can full-voltage start by connecting electromotor with three-phase supply.
Yuebian Electric Co.,Ltd, is one of the largest oil oil filled transformer manufacturers in China, we provide oil immersed transformers, distribution transformer and etc. Want to know more? Please contact us.
