Desk Testing Equipment EN1730 Desk Testing Machine
EN1730 Desk Testing Machine is used for testing the mechanical properties of tables and desks. Can perform the horizontal static load and durability test, vertical static load and impact test.
0
Desk Universal Testing Machine applies the four horizontal air cylinder (with the specified force value) on the four sides of the sample. After a certain number of times of repeating loop, we check if there is any damage on the specimen structure, function and other aspects. So as to understand the product performance and defects and provide reference for improved products.
0
1.The machine adopts frame structure design. The frame is made of high quality industrial aluminum, beautiful and generous.
2.The frame adjustment part of the tester adopts pulley structure design. Can easily adjust the loading position to adapt to different specifications of the sample. Positioning handle makes the positioning easier and improve the efficiency.
3.The bottom fixed block is free to adjust the position to accommodate different specifications of the sample.
4.PLC controller to control the actions of the instrument; the operation is intuitive and simple.
5.Using the precision pressure regulating valve to adjust the pressure to change the loading force value; high precision force sensor sense the force value immediately; each load group adjusts the control individually; the loading force is stable and reliable.
6.Removable loading pad, can easily change the different loading pad to meet the different test requirements.
0
0
Model |
GT-LD09 |
Frame space |
2.5x2.5x2m( Other configurations available on application) |
Testing times |
0-999999( can be adjustment) |
Control method |
PLC control |
Load cell range |
3KN |
Power supply |
AC 220V |
Standard Accessories |
Horizontal loading device 4 sets Vertical loading device 2 set Impact device 1 set GT-LB01-5 Local loading pad 6 pcs Stoppers 4 pcs |
Optional accessories |
GT-LB01-3 Smaller seat loading pad 2 pcs 75mm*75mm Loading pad 4 pcs 100kg Disc superimposed weight 1set Φ300MM Loading pad 1pc Φ400MM Loading pad 1pc |
- QIs your company a trading company or factory?
- AFactory + trade (integration), has 20 years focusing on test instruments field, 6 years exporting experience.
- QAfter an order is placed, when to deliver?
- AGenerally about 10-25days, If we have inventory, we can arrange shipment within 3 days. Please be aware that our production lead times depend on specific items and item quantities.
- QWhat’s the payment term?
- AT/T,L/C and other payment terms could be negotiated.
- QWhat's the warranty and after-sales service?
- A12 months warranty. Feedback to you within 24h and help you to repair your problem controller freely, even it's not from our factory.
- QWhat the standards do you adopt?
- AWe have been adopting the world standards and regulation such as ISO, ASTM, DIN, EN, GB, BS, JIS, ANSI, UL, TAPPI, AATCC, IEC, VDE, and CSA.
- QWhat about the product' services and quality?
- AEach instruments must be carried out 100% quality examination and test when shipping and delivery goods. Product use training, each of our product provide video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer’s company when you need. And our Main clients : SGS, BV and Intertek.
