1300mm 1600mm Customized Large Roll-to-sheet Soft Material Release Film pe Laminating Cutting Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Other
Year Established:
1991
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Factory Custom Auto Integrated Anti-stick Conveyor Belt Rubber Cutting MachineNegotiableMOQ: 1 -
Automatic Printed Paper Cutter Servo Customized Motor Roll-to-sheet Laminating Cutting Machine With Swing Arm FunctionNegotiableMOQ: 1
-
High Speed Automatic Roll Paper Label Cutting Machine Slitting RewinderNegotiableMOQ: 1
-
Transport Packaging Accessories Gasket Cutting MachineNegotiableMOQ: 1
-
Automatic Hot Cold Knife Nylon Webbing Ribbon Fabric Cutter Elastic Rubber Band Tape Microcomputer Cutting MachineNegotiableMOQ: 1
Product Overview
It is suitable for cutting various coil materials such as PET, PC, PVC, PCB, FPC, copper and aluminum foil, lithium battery film, flannel, metal flakes, etc. This machine uses servo motor to pull the material, imported PLC touch screen operation, and the length can be set arbitrarily , Quantity and speed, can be cut separately, making it easy for operators to load and unload. It can be equipped with static eliminator, cutting edge conveyor belt device, photoelectric point-finding device and functions such as material start and no material stop. It can be used with other equipment simultaneously.
FEATURES AT A GLANCE
This machine employs microcomputer controller to set belt cutting length.
The cutting length is accurate.
Operation is easy.
Waste rate is low.
Manufacturing experience: 30 years
Export experience: 20 years
PRODUCT SPECIFICATIONS
model |
HX-1300B |
HX-1600B |
||
Voltage |
380V |
380V |
||
Total power |
5KW |
6KW |
||
net weight |
2000Kg |
2500Kg |
||
Cutting accuracy |
±0.1mm |
±0.1mm |
||
Cutting length |
0.1~9999.9mm |
0.1~9999.9mm |
||
Cutting width |
1~1300mm |
1~1600mm |
||
Cutting speed |
1-100刀/分(cut/min) |
1-100刀/分(cut/min) |
||
Packing size |
3130x2240x1670mm |
3130x2540x1670mm |
Special custom
1600mm Large-scale receiving platform
laminating function
Up and down the double-sided laminating
slitting function
Slitting and trimming
PRODUCT CONFIGURATION
Extra long cutter
Touch screen
Asynchronous motor
Product packaging
Company Profile
We are a team of industry professionals with strong backgrounds in cutting, die cutting,slitting, laminating and rolling. Other related machines in our fields can be customized based on your specific requirements.
Kunshan Hexin Precise Machinery is located in Kunshan city,Jiangsu province. We are near Shanghai,40 minutes away from Shanghai Hongqiao airport by car and 18 minutes by high speed train. Established in 2007, we have been dedicated on converting machines which are used before and after printing for over 10 years.
Our belief is “people-oriented, technology-first, integrity-centered and brand idea” to provide customers reliable products,
perfect service.Our products are widely applied in laminating, slitting and die cutting for shield materials, sticky materials,
insulating materials, conductive materials, electronic materials. Sizing cutting for strings, belts, rolls in bag line, shoe and
cap line and plastic and rubber line.
Kunshan Hexin Precise Machinery is located in Kunshan city,Jiangsu province. We are near Shanghai,40 minutes away from Shanghai Hongqiao airport by car and 18 minutes by high speed train. Established in 2007, we have been dedicated on converting machines which are used before and after printing for over 10 years.
Our belief is “people-oriented, technology-first, integrity-centered and brand idea” to provide customers reliable products,
perfect service.Our products are widely applied in laminating, slitting and die cutting for shield materials, sticky materials,
insulating materials, conductive materials, electronic materials. Sizing cutting for strings, belts, rolls in bag line, shoe and
cap line and plastic and rubber line.
