Help CenterKRC 118 73/2 R1F Ericsson Remote Radio Unit RRUS 01 B3 1800MHz
Related Products
-
BOE 602 14/1 R16B Ericsson BTS Base StationNegotiableMOQ: 1 Piece -
KRC 118 59/2 Ericsson RUS 01 B4 Radio Unit 80W Radio TransceiverNegotiableMOQ: 1 Piece
-
Ericsson Base Station RBS 6601 DUW 30 01 KDU 127 161/3NegotiableMOQ: 1 Piece
-
RNT447 38/02 Ericsson RRU 6488 DC 5G Connector RNT 447 38/02NegotiableMOQ: 1 Piece
-
Ericsson KRY 101 1946 GPS Splitter R1A KRY1011946NegotiableMOQ: 1 Piece
RRUS 01 B3 1800MHz
RRUS – REMOTE RADIO UNITS
RBS6601 is the largest support 24TRX capacity, will support 48TRX, through the TG synchronization, can achieve a cascade of multiple RBS6601, to support a greater allocation of capacity.
RBS6601 uses the typical configuration of RRUS 01 B0:
Single band S8/8/8, for example:900MHz or 1800MHz.
Dual band S4/4/4 (900MHz) +S4/4/4 (1800MHz).
Treatment of RRUS01 RF unit responsible for radio frequency signals.
RF performance:
· GSM, WCDMA, LTE
· 4 carriers over 20 MHz IBW
· Output power 4x15W or 4x20W(IPM)
· The receiver sensitivity -113dBm
Size & weight
· Size: 600 x 350 x 112 mm
· weight: 20kg
Power Supply
· The input voltage: -48 VDC or AC
Environmental Science
· Temperature range: -40ºC to +55 ºC
KDU 137 834/1
KDU 137 739/1
SVB 154 600/23
BFL 901 009/1
KRC 118 72/1
KRC 118 76/1
KRC 118 73/2
KRC 161 264/1
KRC 161 282/2
BMG 907 040/1
BML 901 250/1
DUL21 01 |
KDU 137 834/1 |
KDU 137 834/1 R1C |
DUL contains the baseband, control and exchange, and for LET RBS S1 and the Mub interface. |
TCU 02 01 |
KDU 137 739/1 |
KDU 137 739/1 R1G |
|
MU |
SVB 154 600/23 |
SVB 154 600/23 R1C |
The main control unit, can be placed in the two block of DUG20. |
SUP 6601 |
BFL 901 009/1 |
BFL 901 009/1 R3B |
MU shell power and alarm system, to provide power for the DUG. |
RRUS 01 B0 |
KRC 118 72/1 |
KRC 118 72/1 R1A |
Output power: 4X15W/ 900M 4 carrier / receiving sensitivity: -113dBm |
RRUS 01 B1 |
KRC 118 76/1 |
KRC 118 76/1 R2C |
4 carriers,Output power of 4X15W or 4X20W (IPM),Input voltage: -48 VDC or AC. |
RRUS 01 B3 |
KRC 118 73/2 |
KRC 118 73/2 R1F |
Output power: 4X15W/ 1800M 4 carrier / receiving sensitivity: -113dBm |
RRUS 02 B0 |
KRC 161 264/1 |
KRC 161 264/1 A1G |
24 carriers 25MHz(900MHz),MU: -48V RRU: -48V/AC,Only for RBS6000. |
RRUS 12 B3 |
KRC 161 282/2 |
KRC 161 282/2 R1E |
8 carriers,Output power of 4X15W or 4X20W (IPM),Input voltage: -48 VDC or AC |
ACCU |
BMG 907 040/1 |
BMG 907 040/1 R1B |
|
PSU AC 02 |
BML 901 250/1 |
BML 901 250/1 R1D |
RBS6601 RRU outdoor AC power module |
We have Ericsson KRC 118 73/2 for sale, both refurbished and new, at prices typically up to 90% less than the original vendor price. Our super fast turnaround times and high quality stock located all around the world, mean we can ship same-day replacements exactly to where they are needed, minimising network downtime as much as possible.
The Ericsson KRC 118 73/2 like all of our hardware, is fully inspected and repackaged in our ESD and OEM compliant facility by our expert team and comes backed by a comprehensive warranty as standard.Whether you require a brand new product or one that has been refurbished, we source only the highest quality and environmentally-green market equipment. This is all available at the best possible prices, passing the substantial cost benefits directly back to you.
The Ericsson KRC 118 73/2 represents only one item available from our world class portfolio of hardware. This portfolio includes very well known industry names like Nokia, Huawei,ZTE,Siemens, Nortel, Ericsson, Alcatel, Lucent and many more. With almost one million parts in stock, we are grateful to be able to share it with our clients
