Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260

Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 thumbnail-1
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 thumbnail-2
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 thumbnail-3
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 thumbnail-4
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 thumbnail-5
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 photo-1
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 photo-2
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 photo-3
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 photo-4
Fast Speed Blister Packing Machine Candy Capsule Tablet DPH-260 photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Buying Office
Year Established:
1997
Annual Export Value:
US$2.5 Million - US$5 Million
Contact Supplier Request Quote Chat Now
Sino Pharmaceutical Equipment Development (Liaoyang) Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description
Note: Standard machine without the outlet conveyor

Specification

Product Name
DPH-260 high-speed aluminum-plastic blister packaging machine
Packaging Material
Pvc- Alu
Cutting Frequency
Max.150 cutting/min
Max forming area
Max.260x250mm
Forming depth
Max. 12mm
Total Power
About 18KW
Packing material
PVC reel：0.15-0.5×260 mm
PTP Alu foil：0.02-0.035×260 mm
Reel Aperture：70-76 mm
voltage
380 50HZ
Compressed air
>0.2m3 /min 0.4-0.6MPA
Mold cooling
water:60L/H
Noise
75dB(A)
Overall Dimension
3600x1250x1800 mm（L×W×H）
Weight
3000Kg
Detailed Images
Heating station
Vibrating feeding device

Forming Station

Forming Traction Station

Heating Sealing Station

Batch Number Station

Vibrating feeding device

Cutting station

Packing & Delivery
