Plastic Bottle Beverage Bottle Shrink Sleeve Labeling Machine 3000-6000 Bottles/hour
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1995
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
High Speed Water Bottle Sleeve Shrink Labeling Machine for PET BottlesNegotiableMOQ: 1 -
Automatic Bottle Sleeve Shrink Labeling Machine PVC PET OPS LabelNegotiableMOQ: 1
-
Automatic Heat Shrink Bottle Labeling Machine 60-120mm Bottle DiameterNegotiableMOQ: 1
-
Automatic PVC PET OPS Shrink Label Sleeve Machine 3000-6000 Bottles/hourNegotiableMOQ: 1
-
3000-6000 Bottles/hour Automatic Sleeve Shrink Labelling Machine for PET BottlesNegotiableMOQ: 1
Recommend Products
Products Description
This equipment is a fully automatic intelligent packaging line that integrates bottle feeding, bottle separation, sleeve labeling and shrink labeling functions. It is designed with real high speed, precise positioning, simplified manpower and perfect packaging. It is suitable for the outer packaging of beverages, condiments, cosmetics and other related products, and has beautiful appearance and easy cleaning and maintenance.
Product Name |
SED-100RTB-K Sleeve Labeling Machine |
Capacity |
3000-6000 bottles/hour |
Bottle diameter |
60mm~120mm, special size can be customized |
Bottle height |
30 mm -320 mm, special height can be customized |
Label length |
30mm～250mm |
Label thickness |
0.027mm～0.13mm |
Label material |
PVC, PET, OPS |
Voltage |
AC380V, 50/60HZ, 3-phase |
Power |
3KW |
Dimensions |
2100*850*2000mm |
Total weight |
900 kg |
Details Images
Electric Cabinet and Feeding Buffer Unit
Photoelectric Sensor Unit and Automatic Tension Feeding Unit
Synchronous Under-brush Unit and Synchronous Bottle Driving Unit
Feature
1. The mechanism installs a photoelectric sensor at the material tray. When the label is nearly used up, it will stop and alarm, and leave a segment of the label for the operator to connect the label; other manufacturers' equipment does not have this function, which finishes the label easily, and the operator has to load the label again.
2. The mechanism adopts dual-signal feeding, which can implement automatic switch between high-speed and low-speed or stop, thereby ensuring the stable linear speed of the label feeding, improving the accuracy of label cutting, and reducing the phenomenon of inconsistent label length; other manufacturers feed labels with single signal.
