Low Noise Level Horizontal Automatic Soap Cartoning Carton Packaging Machine
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Business Service (Transportation, finance, travel, Ads, etc)
Year Established:
1995
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Customizable Automatic Granule Bag Packing Machine 30-60 Packages / MinNegotiableMOQ: 1 -
Video Technical Support Vertical Automatic Bag Packing Machine for GranulesNegotiableMOQ: 1
-
Wide Range of Application Carton Box Packing Cartoning MachineNegotiableMOQ: 1
-
Automatic Soap Cartoning Carton Packaging Machine With Video Technical SupportNegotiableMOQ: 1
-
Pharmaceutical Chemical Food Industries Horizontal Carton Box Packaging Cartoning MachineNegotiableMOQ: 1
Recommend Products
Products Description
This machine is a fully automatic continuous cartoning machine, a high-performance product integrating machine, light, electricity, and gas. It is suitable for automatic processing of aluminum-plastic blister plates, bottles, hoses, soft double aluminum, bag-like items, etc. It can be packed in boxes, and can be matched with them to form a packaging production line.
Items |
Specification |
Cartonning speed |
260boxes/min |
Quality |
250-350g/m2 (It’s decided by the box size.) |
Size, L×W×H |
(70-180) × (35-80) × (14-50), mm |
Quality |
60-70g/m2 |
Size when it’s unfolded, L×W |
(80-250) × (90-170), mm |
Folding |
1-4folds |
Working pressure |
Not less than 0.6Mpa |
Consumption |
About 160 ~ 200L/min |
Power supply |
380V, 50Hz |
Main power |
5Kw |
Overall dimension, L×W×H |
4800 × 1600 × 1860, mm |
Net weight |
3000Kg |
Feature
1. No products do not suck leaflet. Not leaflet does not suck carton.
2. When there is no product or the product supply is not in place, the machine will idle without pushing the product. When the product is restored to supply, it will run automatically, and the product will stop automatically when the product is not in place.
3. Low compressed air and vacuum negative pressure shutdown alarm.
4. The multi-station servo pushing mechanism can save the front operation space of the machine, and make the operation and maintenance of the machine more convenient.
5. A very simple product specification change can be made through the dial scale handwheel.
