3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price

3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price thumbnail-1
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price thumbnail-2
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price thumbnail-3
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price thumbnail-4
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price thumbnail-5
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price photo-1
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price photo-2
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price photo-3
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price photo-4
3D 4axis Wood Cnc Router Carving Machine 1325 Woodworking With the Rotary Price photo-5
Negotiable MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Agent
Year Established:
2011
Annual Export Value:
US$5 Million - US$10 Million
Contact Supplier Request Quote Chat Now
Jinan Senke CNC Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Product Description

1.All of the spindles can work together to save your time and costs,while any one of them can work alone,too.
2.We can supply 2-8 spindles for a machine.The number and power of the spindle are to be adjusted by the costumer's needs.
3.You can adjust the distance between two spindles to satisfy your requirements.
4.The solid and permanent structure plus unique design make the machine with long service lite performs well.

Product Name
3D 4axis wood cnc router carving machine 1325 woodworking with the rotary price
Working area
1300*2500*200mm
Body structure
welding
Spindle power
3kw/5kw/7kw(can be choiced)water or air cooling spindle
Spindle Speed
0-24,000rpm
Control system
Nc-studio/DSP/MACH 3 etc
X, Y Structure
Tainwan HIWIN square rails
Z Structure
ball screw
Driver type
stepper or servo for choice
X, Y Resolution
<0.01mm
Max Moving Speed
35000mm/min
Max Engraving Speed
18000mm/min
XYZ traveling positioning accuracy
±0.03/300mm
XYZ repositioning accuracy
±0.03mm
Working Dictate
G Code
Tool sensor
Yes,included
Auto oil lubricator
Yes,included
Wire protect
Yes,included
Running Environment
Temperature: 0°C~45°C
Products Show
Our Company
Packing & Delivery

Packing Details  : wooden box

Delivery Details : 13-15 working days after the payment




Our Certifications
Customer Photo


Thanks for all users and customers surpport and trust,till now,Senke CNC Machine will work for more and more customers.

FAQ

Q: Are you trading company or manufacturer ?

A: We are the direct manufacturer.

Q: How long is your delivery time?

A: It is about 13-15 working days after the payment.

Q: Do you provide samples ?

A: Yes, we could offer the sample as for your demand.

Q: What is your terms of payment ?

A: 50% in advance,50% before shippment
