High Strength Durable Molded Frp Plastic Bar Grating Fiberglass Frp Plastic Grid Grating Platform
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Distributor/Wholesaler
Year Established:
2000
Annual Export Value:
US$50 Million - US$100 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Fiberglass Grp Open Mesh Flooring Grating Plastic Grid SheetsNegotiableMOQ: 1 -
GFP/FRP Fiberglass Roof Panels Floor Grating Walkway Plastic Frp GrateNegotiableMOQ: 1
-
Anti Slip FRP Dock Panels and Fiberglass Reinforced Plastic Grating Walkways SheetsNegotiableMOQ: 1
-
Factory Supply Fiberglass Frp Grp Floor Grating Price Plastic Walkway GrillNegotiableMOQ: 1
-
Factory Supply Anti Slip Molded 38mm Square Mesh Fiberglass GratingNegotiableMOQ: 1
High Strength Durable molded frp plastic bar grating fiberglass frp plastic grid grating platform
Molded fiberglass reinforced plastic is made by putting the molding material into a metal mold through a certain process.
The specifications of molded products are generally determined by the shape, size, and accuracy of the mold, and can be molded into parts with complex shapes and accurate dimensions.
However, due to the complexity of designing and manufacturing molds, the specifications and sizes of molded products are restricted.
LanYu offer the widest selection with panel sizes ,colors and slip resistant surfaces, Clients can avail FRP Gratings suiting your specific requirements.
Mesh Size
(mm)
|
Full panel size
(mm)
|
Thickness
(mm)
|
Recommended Span
(200kg/m2)
|
38.1x38.1mm
(1.5''x1.5'') |
1220x3660mm
1000x4038mm
1530x3130mm
1220x4007mm
1526x4046mm
|
25mm
|
≤800mm
|
1220x3660mm
1220x4038mm
|
30mm |
≤1000mm |
|
1220x3660mm
1530x4007mm
1220x4038mm
|
38mm
|
≤1300mm
|
|
Upper19x19mm Below: 38.1x38.1mm |
1224x4042mm |
30mm
(double mesh layers)
|
- |
50.8x50.8mm (2''x2'') |
1220x4020mm |
50mm |
≤1700mm |
100x25mm (4''x1'') |
1010x4030mm |
25mm |
- |
Commonly used alkali-free fiber, medium alkali fiber is rarely used
Type
|
Composition (%) |
||||||||||||
SiO2 |
Al2O3 |
Fe2o3 |
B2O3 |
Cao |
MgO |
NaO |
|||||||
Alkali-free fiber |
53.3 |
15.3 |
little |
10.0 |
16.3 |
4.5 |
＜0.5 |
||||||
Medium Alkaline Fiber |
67.3 |
7.0 |
little |
- |
9.5 |
4.2 |
＜12.0 |
||||||
Product Description
Fiberglass material feature:
1. Density
The density of FRP is small (1.4~2.0g/cm), which is 1/6-1/4 of ordinary steel, about 1/3 lighter than aluminum, but its mechanical strength can reach or exceed the level of ordinary steel, and its strength even exceeds Special alloy steel.
2. Thermal conductivity
FRP has poor thermal conductivity, low thermal conductivity, and low linear expansion coefficient (thermal conductivity is only 1/1000~1/100 of the amount of gold). So it is an excellent protective and flame-resistant material.
3. Heat resistance
FRP has good heat resistance, The long-term use temperature of high-performance resin-based composite materials generally does not exceed 250 ℃, while the general FRP is 60~100 ℃.
4. Electrical insulation performance
FRP has good electrical insulation properties, can transmit high-frequency microwaves, does not reflect electromagnetic waves, etc., which is unmatched by metal materials.
5. Corrosion resistance
The common thermosetting glass fiber reinforced plastic has good corrosion resistance, and has good resistance to sea water, atmosphere, and low-concentration acids, alkalis, and salts.
Accessories for C clip and M clip:
Fibreglass grating frp molded grating
>> Exellent loadability
>> Lightweight, high impact
>> Fire resistant
>> Slip and age resistant
>> Corrosion & chemical resistant
>> Non-magnetic & insulation
>> Fire resistant
>> Slip and age resistant
>> Corrosion & chemical resistant
>> Non-magnetic & insulation
Resin Base |
Description |
Corrosion Resistance |
Available Colour |
Max.Oper.Tem |
Vinyl Ester |
Superior Corrosion Resistance and Fire Retardant |
Excellent |
Dark gray Orange Yellow |
110℃ |
Isophthalic |
Industrial Grade Corrosion Resistence and Fire Retardant |
Very Good |
Green Yellow Light Grey |
105℃ |
Orthophthalic |
Moderate Corrosion Resistence and Fire Retardant |
Normal |
Green Light Grey |
70℃ |
frp fiberglass moulded driveway drain grating for outdoor grate
FRP grating application include floor systems, walkways, work platforms, stairs, ramps, trench covers and catwalks, Lanyu integral, long-lasting anti-slip top surface makes the grating of choice in many Industries. It is preferred when slippery working conditions are present. Whether your are building a Power plant, Chemical plants, Marine engineering, Port Engineering, Lanyu will cover your project and stay in your budget.
Packing & Delivery
Fibreglass grating frp molded grating |
||
Packing
|
1. Protected by stretch film; |
|
2. Fasten by packing banding and packed on pallet |
||
3. Grating corners are protected by FRP angle or thick papercard. |
||
Delivery
|
1. Stock grating: 3-5 working days. |
|
2.. Manufacturing: 1-2 weeks, or depends on the order quantity. |
||
Welcome your inquiry about FRP grating anytime.
