Water borehole inspection well logging camera
Main Specification of PIW-D500 well logging camera
|
Main Control Box |
Aluminum Alloy Main Machine |
|
Winch |
|
|
Display Screen |
12” High Brightness LED Monitor |
|
Camera |
Dual Camera Pan 360 degree |
|
Depth Counter |
Depth accurate to 0.05m |
|
Well Logging Cable |
Six-core Bearing Pull, Length Optional |
|
Centralizer |
High Elasticity Stainless Steel Centralizer |
Detailed Parameters of PIW-D500 well logging camera
|
Main Control Box |
||
|
* Aluminum Alloy Control Box * Depth Interface: Connect the depth sensor * Depth Zero: Please return the depth to zero before logging, so that the counting is accurate. * Expansion Interface: Video Capture Expansion Interface |
||
|
Winch |
||
|
|
* Electric Winch: control the speed and probe lift by the control button of the main control box * Downhole Pulley: Downhole pulley has the function of depth counting,but need the data line to connect the main control box to use * Split Docking Probe: Easy to exchange the probes of different size and specification. * Down Pulley: down pulley with depth counting function |
|
|
Dual Camera Rotation Camera |
||
|
|
* Camera Size: Φ79mm(Φ50mm wide angle camera Optional) * Camera Material: Zinc-coated, 304 Stainless Steel optional * Camera Window: Explosion-proof Optical Acrylic Glass Or Explosion-proof Glass Window * Camera Pixels: CCD Camera, 1200 TVL High-definition Low-light * Lens Angle: Side 360 degree * Camera Light: Φ79mm dual camera, bottom camera has 6 lights, side camera has a luminous surface. Φ50mm wide angle camera, 6 or 9 lights * Brightness Adjustment: Front and rear lamp beads, can adjust the brightness of the light source through the button in the control box, five-level dimming. * Probe Pressure: Pressure 150bar |
|
|
Pulley |
||
|
|
* Downhole Pulley: Downhole pulley has the function of depth counting, but need the data line to connect the main control box to use * Depth Counting Function: With Japanese Omron depth sensor, the depth display reaches millimeter
|
|
|
Logging Cable |
||
|
|
* Cable Material: Custom Logging Cable * Bearing: 260KG * Outside Diameter: 8 mm * Temperature Tolerance: 65 degree
|
|
