AVT-18T Crawler Chassis Climbing Wall Robot Climb Stairs Track
Negotiable
MOQ: 1 set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Business Type:
Government ministry/Bureau/Commission
Year Established:
1999
Annual Export Value:
US$5 Million - US$10 Million
Payment & Shipping
Payment Methods:
Port of Shipment:
China
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Reasonable Price Chimney Cleaning Equipment for SaleNegotiableMOQ: 1 -
Professional Kitchen Air Chimney Cleaner With 15m CableNegotiableMOQ: 1
-
Hot Selling ACP-2A Chiller Tube Cleaning MachinesNegotiableMOQ: 1
-
Cheaper Price Stair Climber Rubber Track With Drive WheelNegotiableMOQ: 1
-
Rubber Track for Crawler Chassis Robot PlatformNegotiableMOQ: 1
Product Description
AVT-18T rubber track chassis is first and pioneer in heavy loading robot chassis. The body adopts Christie independent suspension. The ground-contacting ratio is higher, 72% making it more stable. Hydraulic shock absorption is more comfortable. The track is made of high-thickness belt base, with better flexibility compared with engineering belt, without frequent jitter of engineering belt, excellently protecting add-on devices.
Application
1. Exploration of inspection
2. The rescue vehicle
3. Scientific research and education
4. Fire control security guard
5. Special photography
6. Special transport
Specification
Item |
Data |
Item |
Data |
|||
Dimension |
1825*1250*585mm |
Inner Space |
650*600*375mm |
|||
Loading Capacity |
500kg |
Self Weight |
350kg |
|||
Rated Speed |
0-3.5km/h |
IP Grade |
IP54 |
|||
Rated Torque |
93.8N·M |
Transmission Ratio |
28 |
|||
Ground Clearance |
210mm |
Max. Span |
600mm |
|||
Drive Wheel Diameter |
190mm |
Max. Gradeability |
30° |
|||
Track Width |
200mm |
Vertical Span |
300mm |
|||
Suspension System |
Christie*12 |
Main Body Material |
304 Stainless Steel / Alloy Steel / Aluminum / Polymer Materials |
|||
Crawler Material |
Quality Rubber Embedded with Kovlar Fiber |
Surface Treatment |
Black Spray (Matte) |
|||
Electrical Parameter |
||||||
Voltage |
DC48V |
Electric Motor |
DC Brushless |
|||
Max. Power |
4000w |
Standby Power Consumption |
≤50w |
|||
Brake Type (Optional) |
Electric Brake |
Braking Voltage |
DC48V |
|||
Encoder (Optional) |
1000-2500TVL |
Driver Model |
6050 |
|||
Remote Controller |
800m |
Remote Control Channels |
9T(Used 3T) |
|||
Features
1. Dimension 1825*1250*585mm, Inner Space 650*600*375mm, 500kg loading capacity, with large open development space.
2. 220mm ground clearance, with excellent through-performance.
3. Christie independent suspension, 72% ground ration.
4. Max. Span 600mm, 10 pairs of shock absorption design, ensuring stable moving in complex ground.
5. Self-tensioning inducer wheel design, ensuring best track tightness timely.
2. 220mm ground clearance, with excellent through-performance.
3. Christie independent suspension, 72% ground ration.
4. Max. Span 600mm, 10 pairs of shock absorption design, ensuring stable moving in complex ground.
5. Self-tensioning inducer wheel design, ensuring best track tightness timely.
6. Can climb stairs.
Packing
Trade Terms
PLACE OF LOADING: Zhengzhou, China
PRICE TERM: EXW Zhengzhou, China
DELIVERY: 7 working days after full payment
PAYMENT: 50% paid by T/T as deposit, the balance 50% paid before machine leaves factory
PACKING: Wooden Case
Company Profit
Zhengzhou Defy Mechanical & Electrical Equipment Co,. Ltd. is a leading robot manufacturer in China, offering robots and mobile solutions for robotic products.
With great development, we have established one-stop solutions for global clients, with our own R&D department, Q&C department, production department, sales department, and after-sales department.Certifications
Our Service
1. Warranty: one year for main machine, excluding easily wear parts. During this period, in case of damage or breakdown, we will repair to replace spare part freely, while the buyer should bear overseas freight.
2. Spare Parts: most of our spare parts are compatible with international standard. While, we offer spare parts all year round at cost price for our former clients.
3. Operation and Maintenance: we will offer you detailed operation manual, ensuring you can use it perfectly.
4. Overseas Installation & Training: we offer overseas service if necessary. The buyer should bear traveling, housing, eating and salary cost during our technician stays there.
2. Spare Parts: most of our spare parts are compatible with international standard. While, we offer spare parts all year round at cost price for our former clients.
3. Operation and Maintenance: we will offer you detailed operation manual, ensuring you can use it perfectly.
4. Overseas Installation & Training: we offer overseas service if necessary. The buyer should bear traveling, housing, eating and salary cost during our technician stays there.
5. Online Service: your question will be answer within 24 hours during working days, 48 hours during holiday.
FAQ
Q1. What is your terms of packing?
we usually use wooden cases. If you have legally registered a patent,After receiving your authorization, we can pack the goods into your brand box.
Q2. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A Generally, it will take 3to 7days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
we usually use wooden cases. If you have legally registered a patent,After receiving your authorization, we can pack the goods into your brand box.
Q2. What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q3. What is your terms of delivery
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A Generally, it will take 3to 7days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q6. What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q7. Do you test all your goods before delivery
A: Yes, we have 100% test before delivery
Q8: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
