Mitsubishi PLC module FX5-40SSC-S

FX5-40SSC-S Mitsubishi 4-axis simple motion controller module,

FX5-40SSC-S parameter description: 4-axis linear interpolation, 2-axis arc interpolation, control units mm, inch, degree, pulse, 600 data/1-axis, SSCNET III/H connection.

Specification of Mitsubishi 4-axis simple motion controller module FX5-40SSC-S:


[Number of control axes] 4 axes


[Operation cycle] 0.888 ms, 1.777 ms


[Interpolation function] Linear interpolation (4-axis), 2-axis arc interpolation


[Control method] PTP control, trajectory control (straight line and arc can be set), speed control, speed/torque control, positioning control


[Acceleration and deceleration treatment] Trapezoidal acceleration and deceleration, approximate S-shaped acceleration and deceleration


[Correction function] Electronic gear, backlash, close to passing through


[Synchronous control]


Input axis: servo input axis, synchronous encoder axis, command generation axis


. Output shaft: camshaft


[Cam control]


Number of cam logins: 64


Cam data format: stroke data format, coordinate data format


Automatic generation of cams: automatic generation of rotating cams


[Control unit] mm, inch, degree, pulse


[Positioning data] 600 data/axis


[Backup] Parameters, positioning data, and block startup data can be saved through flash memory (without battery)


[Origin regression function] Near point DOG method, counting method 1, counting method 2, data setting method, and proportional origin signal detection method


Equipped with high-speed origin return function.


Home reset - auxiliary functions include OPR retry and OP drift


[Servo amplifier connection method] SSCNET III/H


[Positioning]


Linear control: Linear interpolation control (4-axis) (synthetic speed, reference axis speed)


Positioning control: Positioning control (4-axis)


2 axis arc interpolation: interpolation * * *, center point***


Speed control: Speed control (4-axis)


Speed/position switching control: incremental mode/mode


Position and speed switching control: incremental mode


Current value change: position * * *, starting number for current value change***


NOP command: Yes


JUMP command: conditional, unconditional


LOOP/LEND: Yes


Height position control: block start, conditional start, weight start, simultaneous start, repeated start


[Manual control]


JOG operation: Yes


Micro operation: Yes


Manual pulse generator: It may be connected to 1 unit (in increments) with a unit magnification of 1-10000 times.


[Extended control (speed and torque control)] does not include speed control and torque control of the position loop


The position system corresponds to the battery connected to the servo amplifier


[Synchronous encoder interface] 4ch, built-in interface 1ch


[Limit control function]


Speed control function: speed control value, JOG speed control value


Torque limit value change function: positive direction torque limit value, negative direction torque limit value


Emergency stop: effective/ineffective switching function


Software travel range function: current value/given value range check


Hardware travel range function: Yes


[Control content change function] includes speed change function, coverage function (0-300%), acceleration/deceleration time change function


Torque change function, target position change function


[Other functions]


M code output function: Yes


Step function: deceleration unit, data No. Unit


Skip function: through the CPU of the PLC, through external command signals


Teaching function: Yes


[Parameter initialization] Yes


[External input signal setting function] Through CPU, servo amplifier


[Event History Recording Function] Yes


[Symbol detection function] Normal mode, * * * Times mode, Ring buffer mode


Symbol detection signal: 4 points


Symbol detection setting: 16


[Any data monitor function] 4 points/axis


[Driver communication function] Yes


[SSCNET communication disconnect/reconnect function] Yes


[Digital oscilloscope function] 16CH each for bit data and word data





2. Basic unit specifications


[Number of control axes] 4 axes


[Servo amplifier connection method] SSCNET III/H


[Extended distance] SSCNET III/H 400m


[Inter office distance] 100m


[Peripheral device interface] is composed of a CPU unit (Ethernet)


[Manual pulse generator operation function] 1 connectable


[Synchronous encoder operation] 4 sets


[Input signal (DI)]


Input points: 4 points


Input method: positive/negative shared


Rated input voltage/current: DC24V/approximately 5mA


Voltage usage range: DC19.2~26.4V


ON voltage/current: DC17.5V or above/3.5mA or above


OFF voltage/current: below DC7V/below 1.0mA


Input resistance: approximately 6.8k Ω


Response time: less than 1ms


Wire size: AWG24 (0.2mm2)


[Emergency stop input signal (EMI)]


Input points: 1 point


Input method: positive/negative shared


Rated input voltage/current: DC24V/approximately 5mA


Voltage usage range: DC19.2~26.4V


ON voltage/current: DC17.5V or above/3.5mA or above


OFF voltage/current: below DC7V/below 1.0mA


Input resistance: approximately 6.8k Ω


Response time: below 4ms


Wire size: AWG24 (0.2mm2)


[Signal input form] A-phase/B-phase (4x/2x/1x), pulse/sign


[Manual pulse generator/incremental synchronous encoder signal]


Differential output type (equivalent to 26LS31)


Input frequency: 1Mpulse (4Mpulse/s at 4x)


Pulse width: 1 μ Above s


Rising and falling edge time: 0.25 μ Below s


Bit difference: 0.25 μ Above s


Rated input voltage: below DC5.5V


High voltage/low voltage: DC2.0-5.25V/DC0-0.8V


Differential voltage: ± 0.2V


Cable length: 30m


Voltage output/open collector type (DC5V)


Input frequency: 200kpulse/s


Pulse width: 5 μ Above s


Rising and falling edge time: 1.2 μ Below s


Bit difference: 1.2 μ Above s


Rated input voltage: below DC5.5V


High voltage/low voltage: DC3.0-5.25V/2mA below, DC0-1V/5mA above


Differential voltage: ± 0.2V


Cable length: 20m


[DC24 internal consumption current] 0.25A


[External dimensions H * W * D] 90 * 50 * 83mm


[Weight] 0.3kg
