、 Product features:
1. Adopting precision LCD screen microcomputer intelligent PID control technology, the system has temperature control, timing, and overtemperature alarm functions, with RS485 microcomputer interface; The control instruments and all electrical appliances are treated with composite explosion-proof technologies such as explosion-proof, sealing, and intrinsic safety. The sensors are protected by safety barriers to ensure the safe and reliable use of the product.
2. Standard with heat dissipation fan, maintenance free, and high durability. Combining perfect air duct design to ensure uniform temperature inside the working chamber;
3. Mirror stainless steel inner liner, with features such as acid alkali resistance and corrosion resistance.
The heating and constant temperature system inside the explosion-proof drying box adopts explosion-proof electric heaters and explosion-proof fans.
5. Obtained the explosion-proof qualification certificate issued by the Quality Supervision and Inspection Center for explosion-proof electrical products. (Explosion proof certification mark: Ex d IIB T4 Gb)
six
2、 Applicable scope:
Yingpeng explosion-proof drying oven is suitable for related fields such as petroleum, chemical, medical, pharmaceutical, scientific research, laboratory, etc. It can be used in hazardous areas with temperatures ranging from T2 to T4, such as flammable and explosive materials. The heating adopts explosion-proof heating pipes, which have the characteristics of good temperature uniformity and high temperature control accuracy.
3、 The execution standards for this series of products are as follows:
GB3836.1-2010 Explosive Atmospheres - Part 1: General Requirements for Equipment
GB3836.2-2010 Explosive Atmospheres - Part 2: Equipment Protected by Flameproof Enclosures "d"
4、 Product specifications:
model
voltage
Temperature control range ℃
Timing range accuracy ℃ Fluctuation degree% Power KW Net weight KG Inner liner size (mm) (height * width * depth) External dimensions (mm) (height * width * depth)
BYP-070GX-4D
two hundred and twenty
Room temperature+5-250
0-999 minutes
±0.1
±1
one
36 320*350*350 530*640*550
BYP-070GX-7D 1.2 47 420*450*350 630*740*550
BYP-070GX-13D 1.6
sixty-two
520*550*450 750*890*630
BYP-070GX-25D 2.5 96
750*600*500 980*965*770
