Main technical parameters
Model: BL-50L/QX
Overall dimensions: Φ 145*235mm
Inner groove size: Φ 140*100mm
Capacity: 1.5L
Ultrasonic frequency: 40KHz
Ultrasonic power: 50W
Other configurations: 220V/50Hz power supply
Main performance characteristics
Classic mechanical control, simple and convenient operation
The main material of the washer is 304 high-quality stainless steel
The washer circuit has an automatic frequency sweep function, which can generate continuous pulse jet, making the cleaning effect more obvious and the work more stable
Upgrade and match the circuit and components of the cleaner, resulting in high power conversion rate and low reactive power loss
Standard conventional transducer with a power of 50W/piece and a frequency of 40KHz
Optional single ultrasonic frequencies include 20KHz, 25KHz, 28KHz, 33KHz, and 40KHz
The execution standards for this series of products are as follows:
GB3836.1-2010 Explosive Atmospheres - Part 1: General Requirements for Equipment
GB3836.2-2010 Explosive Atmospheres - Part 2: Equipment Protected by Flameproof Enclosures "d"
GB3836.4-2010 Explosive Atmospheres - Part 4: Equipment Protected by Intrinsically Safe "i"
GB3836.9-2006 "Electrical Equipment for Explosive Gas Atmospheres - Part 9: Encapsulated" m "
GB3836.15-2000 "Electrical Equipment for Explosive Gas Atmospheres - Part 15: Electrical Installation in Hazardous Areas (excluding Coal Mines)"
Applicable scope:
1. This product is suitable for explosive environments such as petrochemical, metallurgical, textile, food, bioengineering, pharmaceutical, warehouse, aerospace engineering, and places with temperature control requirements;
Zone 2.1 and Zone 2 hazardous gas locations
3. Class IIA, IIB, IIC, T1-T4 explosive gas or steam environment;
4. Environmental temperature: -5 ℃~+43 ℃.
