Product Name:Steam To Steam Pure Clean Steam Generators
Sterility - Pure steam used in pharmaceutical processes must be sterile, meaning that it is free from viable microorganisms. The USP and EP have specific requirements for the sterility of pure steam, which typically involves the use of validated sterilization processes.
Endotoxin levels - Endotoxins are bacterial toxins that can cause fever and other adverse effects in humans. Pure steam used in pharmaceutical processes must have low levels of endotoxins, as specified by the USP and EP.
Product Feature:
In compliance with FDA,cGMP and pressure vessel requirements.
Condenser,evaporator is double tube sheet design.
All parts which is connect with feed water ,pure steam and condensate water is SS 316L.
Ensure the welding quality ,automatic track welding use the arc for protection.
Inside surface electro chemical polishing to ensure the stainless steel surface smoothness,outside surface is mat finished.
It can use non paper recorder to achieve no paper record ,or use paper recorder to record critical parameter.
Low point drainage.
Insulated design for energy saving .
Sampling is accessible for quality checking purpose
Stable performance ,easy for maintenance.
FAT will be carried out for each finished PSG to ensure quality before use .
CHONGYANG Water Spec. & Type
| Type | Capacity | Feed Water | Industry Steam | Height(mm) | Length(mm) | Wide(mm) |
| PS100 | 100 | 115 | 130 | 2100 | 900 | 570 |
| PS200 | 200 | 230 | 250 | 2500 | 900 | 570 |
| PS300 | 300 | 345 | 370 | 2500 | 1100 | 680 |
| PS400 | 400 | 460 | 480 | 2600 | 1100 | 680 |
| PS500 | 500 | 575 | 173 | 2600 | 1170 | 720 |
| PS800 | 800 | 920 | 960 | 3500 | 1775 | 930 |
| PS1000 | 1000 | 1150 | 1200 | 3700 | 1775 | 930 |
| PS2000 | 2000 | 2300 | 2400 | 4000 | 2030 | 1900 |
| PS3000 | 3000 | 3450 | 3600 | 4850 | 2030 | 1900 |
| PS4000 | 4000 | 4600 | 4800 | 5100 | 2200 |
2100 |
