Automatic Quinoline and Toluene Insolubles Non-Toxicity Tester
Product Model: JF2292Z2
Instrument introduction
This instrument is suitable for the detection of quinoline and toluene insoluble matter in coal tar, modified asphalt, coal tar road oil, wood preservative oil, and coking raw material oil for carbon black.
Technical Parameter
1. Applicable standards: GB/T 2293, GB/T 2292;
2. Temperature control mode: PID programme temperature control
3. Display: Colour touch LCD screen
4. Control mode: PLC automatic control
5. filtration mode: Automatic filtration, automatic drying
6. Cooling mode: Tap water (optional thermostatic bath)
7. Working unit: Toluene insoluble matter,
Quinoline insoluble matter
8. Power of the whole machine: 3KW
9. Instrument size: 630 * 750 * 900mm
10. Net weight：100KG
11. HS Code: 9027899090
Features
1. The whole adopts a fully closed structure to ensure that all toxic gases emitted during the test are filtered by the gas treatment device. To achieve zero leakage of toxic gases and harmless treatment. Ensure that the operator is not harmed by toxic substances.
2. Gas filtration system: adopting multi-stage filtration technology, the experiment can be harmless treatment of harmful gases;
3. Automatic centrifugation is available according to the sample requirements, no need to configure centrifuge separately;
4. Automatic liquid pumping, automatic heating control, automatic stirring and filtration, automatic gas filtration and automatic drying.
5. Non-toxicised pumping structure, no need to take the bottle stopper, the instrument automatically pierces to take the liquid;
6. Improved metal filtration and thermostat device, only need to press the clip to quickly disassemble;
7. Automatic control of reflux speed, with transparent safety shield;
8. Automatic cleaning, draining and drying after the test, convenient for the next test;
9. With three-way test solvent, toluene, quinoline, acetone, in line with standard requirements.
