Help CenterBently Nevada 135489-03 Communication Gateway Module for 3500 Series – Turning 3500 Data Into DCS/PLC Insights
Related Products
-
Bently Nevada 135031-01 Rack Interface I/O Module – Reliable Rack Communications for 3500 Series Protection SystemsUS$ 4216.00MOQ: 1 Blade -
Bently Nevada 136711-01 Temperature Monitoring I/O Module for 3500 Series – Rear I/O for 3500/60 Temperature MonitorUS$ 4216.00MOQ: 1 Blade
-
BENTLY NEVADA 136719-01 – Temperature Monitor Module for 3500 Series Machinery ProtectionUS$ 4216.00MOQ: 1 Blade
-
BENTLY Nevada 140734-05 Dynamic Pressure Monitoring Module – Continuous Combustion and Pulsation Insight for Critical Rotating AssetsUS$ 4216.00MOQ: 1 Blade
-
Bently Nevada 176449-08 Piston Rod Position Monitor – Reliable Rod Motion Tracking for Reciprocating CompressorsUS$ 6216.00MOQ: 1 Blade
Warranty: 365 days
Lead time: In-stock typically ships in 1 week; no more than 1 month at the latest
Payment: 50% advance payment; full payment prior to delivery
Express options: FedEx, UPS, DHL
Modbus connectivity (Ethernet & serial): Typically supports Modbus/TCP for modern networks and Modbus RTU (RS‑232/RS‑485) for legacy DCS/PLC.
Direct rack data access: Reads measurements, alarms, and status from the 3500 backplane without altering protection functions.
Simple integration: From my experience, mapping common tags (overall vibration, alarm statuses, channel OK) is quick and predictable.
One-slot full-height module: Drops into a 3500 rack slot; powered by the rack—no external supply clutter.
Flexible plant use: Works well for adding visibility in control rooms, trending in historians, or driving interlocks via PLC logic.
Service-friendly design: Front-facing comms ports keep commissioning tidy; firmware and configuration are typically handled through standard Bently toolsets.
| Brand / Model | Bently Nevada 135489-03 (Communication Gateway for 3500 Series; commonly aligned with 3500/92) |
| HS Code | 903289 (Automatic regulating or controlling instruments and apparatus) |
| Power Requirements | Powered from 3500 rack backplane; no external power supply required |
| Dimensions & Weight | Standard 3500 full-height module; occupies one rack slot; approx. 0.6–0.8 kg |
| Operating Temperature | Typically 0 to +65 °C (per common 3500 module practice) |
| Signal Input/Output Types | Backplane data from 3500 channels; Modbus RTU (RS‑232/RS‑485) and Modbus/TCP (Ethernet) |
| Communication Interfaces | 10/100BASE‑T Ethernet (RJ‑45); RS‑232/RS‑485 serial |
| Installation Method | Plug-in 3500 rack module; front-panel comms ports; install with rack power secured for safety |
| Compatibility | 3500 Series racks and power supplies (e.g., 3500/15); commonly used alongside 3500/22M TDI |
You’ll typically find the 135489-03 bridging condition and protection data into:
Refineries and petrochemical plants – pulling 3500 alarms to DCS for operator visibility
Power generation – trending turbine and generator bearing data in historians via Modbus/TCP
Pipeline and midstream compression – simple RS‑485 links to PLCs for interlocks
Pulp & paper, mining, and steel – standardizing 3500 outputs to existing control systems
Reliability: Uses the rack backplane rather than field wiring to read measurements; fewer failure points in many cases.
Compatibility: Modbus support makes it a low-friction fit for DCS/PLC across brands—Honeywell, Emerson, Siemens, Rockwell, and others.
Cost-saving: Avoids additional signal conditioners; one module can publish a broad set of tags over Ethernet.
Supportability: Clear tag structures and widely known protocols reduce integration time for system integrators.
Panel/rack: Install in a standard Bently Nevada 3500 rack (well‑ventilated enclosure meeting common cabinet standards, e.g., 19‑inch rack with proper grounding).
Wiring: Use shielded twisted pair for RS‑485; observe proper termination. For Ethernet, use industrial Cat5e/Cat6 with managed switches where possible.
Safety: Power down the rack before insertion/removal. Follow site ESD precautions and lockout/tagout policies.
Configuration: Map required Modbus registers only; unnecessary polling increases network load without benefit.
Routine checks: Verify communication status LEDs during rounds, back up configuration, and keep firmware at a validated revision for your site.
Customer feedback: A rotating equipment engineer told us a swap over a turnaround took ~10 minutes, with tags re-polled by the DCS immediately once IP settings matched.
The 3500 platform is known for rigorous compliance. Units of this type are commonly supplied with CE and UL/cUL marks and are RoHS conformant; some builds may carry additional regional or hazardous area approvals (e.g., Zone 2/Div 2), depending on the exact option set. Documentation provided with your unit will state the specific approvals.
Warranty is 365 days from shipment. If you need a specific certificate set for project turnover dossiers, just let us know in advance so we align the shipment accordingly.
Commonly Paired Components (for planning)3500/15 Power Supply – feeds the rack and modules
3500/22M Transient Data Interface (TDI) – for detailed waveform/diagnostics alongside gateway data
3500/05 or 3500/06 Racks – depending on your slot count and mounting style
