Help CenterFSM300LT Freesor-current Sensor
Related Products
Electricalcharacteristics | ||||||
Type |
FSM050LT |
FSM100LT |
FSM200LT |
FSM300LT |
||
IPN |
Primarynominalinputcurrent |
50 |
100 |
200 |
300 |
A |
Ip |
Measuringrangeofprimarycurrent |
0～±75 |
0～±150 |
0～±300 |
0～±500 |
A |
IsN |
Secondarynominaloutputcurrent |
50 |
50 |
100 |
150 |
mA |
KN |
Conversionratio |
1:1000 |
1:2000 |
1:2000 |
1:2000 |
|
Measuringresistance(Vc=±15V/IpM) |
186(max) |
175(max) |
100(max) |
56(max) |
Ω |
|
RM |
(Vc=±15V/Ip) |
117(max) |
106(max) |
56(max) |
21(max) |
Ω |
(Vc=±18V/IPN) |
304(max) |
293(max) |
130(max) |
75(max) |
Ω |
|
(Vc=±18V/Ip) |
159(max) |
148(max) |
75(max) |
31(max) |
Ω |
|
Vo |
Supplyvoltage |
±12～±18(±5%) |
V |
|||
Io |
Currentconsumption |
Vc=±15V20+I |
mA |
|||
Va |
Insulationvoltage |
Between primary and secondary circuits: 2.5kV rms/50Hz/1 minute |
||||
EL |
Linearity |
%FS |
||||
X |
Accuracy |
TA=25CVc=±15V±0.5 |
% |
|||
Io |
Zerooffsetcurrent |
TA=25℃ |
mA |
|||
IoM |
Residualcurrent |
Ip=0 |
mA |
|||
Ior |
ThermaldriftofI0 |
Ip=0TA=-25～+85℃ |
mA |
|||
Tr |
Responsetime |
μs |
||||
f |
Frequencybandwidth(-3dB) |
DC～100 |
kHz |
|||
