Help CenterBently Nevada 330180-051-CN: Catch Vibration Issues Before They Shake Your Bottom Line
Related Products
-
Bently Nevada 330104-11-25-10-02-00 3300 XL 8mm Probe: Your Vibration Monitoring WorkhorseUS$ 236.00MOQ: 1 Blade -
Bently Nevada 330104-00-22-10-02-00 Proximity Transducer: Reliable Shaft Monitoring for Critical TurbomachineryUS$ 236.00MOQ: 1 Blade
-
Bently Nevada 330104-00-08-90-02-05(CN) 3300 XL 8mm Proximity Probe: Precision Vibration Monitoring for Critical MachineryUS$ 236.00MOQ: 1 Blade
-
Bently Nevada 330104-00-25-10-02-00 3300 XL 8 mm Proximity Probe: Your Turbine’s Early Warning SystemUS$ 236.00MOQ: 1 Blade
-
Bently Nevada 330103-00-07-05-02-05 3300 XL 8 mm Proximity Probe: Precision Shaft Monitoring for Critical MachineryUS$ 1300.00MOQ: 1 Blade
Sub-micron sensitivity – Detects shaft movement as small as 0.1μm, which typically prevents false alarms during startup surges
Wide temp tolerance – Keeps working in -40°C Arctic pipelines or +120°C compressor housings where cheaper sensors drift
Threaded armor cable – Survives oil baths and physical knocks; one refinery client told us theirs lasted 3 years in a slurry pump pit
Plug-and-play calibration – Pre-matched to Bently’s 3500 rack so you skip hours of setup (though I’d still verify with a handheld meter)
| Parameter | Specification |
|---|---|
| Brand/Model | Bently Nevada 330180-051-CN |
| HS Code | 9031.80.9090 (Vibration monitoring sensors) |
| Power Requirements | 18-30 VDC @ 10 mA (compatible with most PLC power supplies) |
| Dimensions & Weight | Ø8mm x 60mm probe / 220g (fits tight spaces near couplings) |
| Operating Temperature | -40°C to +120°C (probe), -20°C to +70°C (cable) |
| Signal Output | -24 VDC to -18 VDC (proportional to shaft displacement) |
| Installation Method | M10 x 1 thread mount (standard in API 670 compliant systems) |
Oil & gas folks stick these on centrifugal compressors where false trips cost $50k/hour in downtime. In power plants, they're monitoring steam turbine critical speeds—especially useful during grid frequency swings. One chemical plant client uses them on agitator motors in sulfuric acid tanks; the stainless steel housing shrugs off fumes that kill ordinary sensors. It's not magic for low-speed pumps though; below 1,200 RPM, you might want supplemental accelerometers.
Reliability here isn't just about uptime—it's about not wasting engineers' time chasing ghosts. The 365-day warranty covers calibration drift (a real headache with Chinese clones), and since it uses standard 5-11mm clearance ranges, you won't need custom spacers. In many cases, swapping old probes takes under 20 minutes during planned outages. Oh, and if your control system runs Bently 3500 racks? Firmware updates happen over the same cable—no extra comms hardware.
Installation & Maintenance Reality CheckMount it on rigid surfaces only—vibrating brackets cause signal noise. I've seen guys bolt probes directly to motor housings that flex, then wonder why readings jump. Keep cable runs away from VFDs; if you must cross power lines, do it at 90° angles. For maintenance: wipe the probe tip monthly with isopropyl (dirt changes sensitivity), and recalibrate annually unless your ISO 55000 audit demands quarterly checks. Skip the "clean with compressed air" advice—moisture in shop air ruins the coil.
Certifications That Actually MatterCE marked per Machinery Directive 2006/42/EC, RoHS 3 compliant (no more mercury switches!), and built under ISO 9001:2015 at the Minden, NV plant. Not ATEX-rated—so keep it out of Zone 0 areas. Warranty covers defects but not physical damage; that time a refinery dropped a wrench on one during installation? Not covered. Still, 97% of failures we see are cable-related, not the probe itself.
Ordering? We keep 120+ in stock—50% deposit gets it shipped FedEx/UPS/DHL in 5 business days. Full payment before dispatch. No restocking fees if you size it right (hint: check your existing probe's thread pitch first).
